SWITCH DISCONNECTORS AND DIRECT CONNECTION
Order Device and Kit (where required) separately.
Switch Disconnector Device Kit
125
A 2P
1252
SD 18PSC2PLK
125
A 3P
1253
SD
Not Required
125
A 4P
1254
SD 18PSC4PLK
Direct Connection Device Kit
125
A 3P
125
DCB
Not Required
l
50
mm
2
Terminal capacity
l
IEC/EN 60947-3
RESIDUAL CURRENT CIRCUIT BREAKERS
l
Device Kit
100
A 4P 30mA
241/030 18
PSC4PLK
100
A 4P
100
mA
241/100 18
PSC4PLK
100
A 4P
100
mA TD
241/100
TD 18PSC4PLK
100
A 4P 300mA
241/300 18
PSC4PLK
100
A 4P
300
mA TD
241/300
TD 18PSC4PLK
l
Type AC
l
35
mm
2
Terminal capacity
l
BS EN 61008
18
PSC12MRF
18
PSC12MR
IP18PSC12MR
18
PS2PLK
18
PSC4PLK
1252
SD 1253SD 1254SD
241/100
125
A TYPE B DISTRIBUTION BOARDS AND THEIR INCOMING OPTIONS
POLESTAR COMPACT 125A INCOMER OPTIONS
l
Incoming options -
order separately
:
125
A Switch Disconnector TP/4P - 50mm
2
100
A RCCB 4P - 35mm
2
125
A Direct Cable - 50mm
2
l
Integral metering available with Meter Ready
(
MR) board utilising a TP Incoming option
l
Busbars rated at 125A
l
IP31 (Door Closed) or IP66
l
Full compliment of Neutral & Earth terminals
Incoming maximum 70mm
2
Outgoing maximum 25mm
2
l
Allows the fixture of dual Earth bars (IP31)
l
Clean Earth kit available (IP31)
l
All IP31 boards are supplied as standard with
hinged outer door, catch (lock is optional extra)
and removable top/bottom gland plates
l
Neutral busbar supports incorporate an integral
MCB end stop
l
BS EN 60439-3
