1 2
L1 L1 N
3 4 5
36
44
64
6
45 90
44
64
6
1 2
L1
N
L1 L2 L2 L3 L3
3 4 5 6
72
45 90
ENERGY METER DIMENSIONS
C7KT1531 & C7KT1533
C7KT1543 & C7KT1545
POLESTAR COMPACT FINAL CIRCUIT METERING OPTIONS
C7KT1531
80
A SP & TP DIRECT CONNECTION ENERGY METERS
Description LIST No
Single Phase Direct connection Energy Meter
C7KT1531
Single Phase Direct connection Energy Meter (MID)
C7KT1533
Three Phase Direct connection Energy Meter
C7KT1543
Three Phase Direct connection Energy Meter (MID)
C7KT1545
•
Direct Connect kWh meter
•
Pulsed Output
•
DIN rail Mounting
• 35
mm
2
terminal capacity
•
Green Backlit display
CARLO GAVAZZI
kWh
M21
18
MPSC125LP
DUAL METER PACKS
I
410
mm high ‘add on’ assemblies suitable for mounting directly beneath
two surface 125A/200A type B Distribution Boards. Includes two digital
energy meters, six current transformers, all associated fuses & wiring and
flexible interconnections to Distribution Boards. Provides single point
isolation while dual meters allow for separate monitoring of
Light
and
small
Power
energy consumption.
Description 125A 200A
‘
Add-on‘ Dual Meter Pack
18
MPSC125LP 18MPSC250LP
kWh
Kilowatt hours
kW (
)
Real Power (system)
kvarh
Kilovolt amp reactive hours
kvar (
)
Reactive Power (system)
PF (
)
Power Factor (system)
Hz (
)
Frequency (system)
PF L1
Power Factor
PF L2
Power Factor
PF L3
Power Factor
A L1
Current
A L2
Current
A L3
Current
V L1-2
Line Voltage
V L2-3
Line Voltage
V L3-1
Line Voltage
V L1
Phase Voltage
V L2
Phase Voltage
V L3
Phase Voltage
Energy meters within all Loadstar final assemblies display values of:
All include pulsed output as a standard feature.
RS485 port for MODBUS/JBUS (RTU) connections along with complete final assemblies are available on request from our technical support team.
