18 / 81
18
NH PhotoVoltaic
NH14DSRCBMPVF
NH12DSRCBMPVSL
NH10DSRCBMPVHI
NH10DSRCBMPVDR
MAIN SWITCH DUAL SUPPLY PV CONSUMER UNITWITH MID
CERTIFIED GENERATION METER
CAT REF.
DESCRIPTION
NH15DSMPVF
15Way unit with dual supply isolators & 16A SP MCB
NH10DSMPVF
10Way unit with dual supply isolators & 16A SP MCB
NH14DSRCBMPVF 14Way unit with dual supply isolators & 16A DP RCBO
NH9DSRCBMPVF 9Way unit with dual supply isolators & 16A DP RCBO
MAIN SWITCH DUAL SUPPLY PV CONSUMER UNIT
NH16DSPVF
16Way unit with dual supply isolators & 16A SP MCB
NH11DSPVF
11Way unit with dual supply isolators & 16A SP MCB
NH15DSRCBPVF
15Way unit with dual supply isolators & 16A DP RCBO
NH10DSRCBPVF
10Way unit with dual supply isolators & 16A DP RCBO
Double Pole MCB options available on request
SPLIT LOAD DUAL SUPPLY PV CONSUMER UNITWITH MID
CERTIFIED GENERATION METER
CAT REF.
DESCRIPTION
NH13DSMPVSL
13Way unit with dual supply isolators & 16A SP MCB
NH8DSMPVSL
8Way unit with dual supply isolators & 16A SP MCB
NH12DSRCBMPVSL 12Way unit with dual supply isolators & 16A DP RCBO
NH7DSRCBMPVSL 7Way unit with dual supply isolators & 16A DP RCBO
SPLIT LOAD DUAL SUPPLY PV CONSUMER UNIT
NH14DSPVSL
14Way unit with dual supply isolators & 16A SP MCB
NH9DSPVSL
9Way unit with dual supply isolators & 16A SP MCB
NH13DSRCBPVSL 13Way unit with dual supply isolators & 16A DP RCBO
NH8DSRCBPVSL
8Way unit with dual supply isolators & 16A DP RCBO
Double Pole MCB options available on request
HIGH INTEGRITY DUAL SUPPLY PV CONSUMER UNITWITH MID
CERTIFIED GENERATION METER
CAT REF.
DESCRIPTION
NH11DSMPVHI
11Way unit with dual supply isolators & 16A SP MCB
NH10DSRCBMPVHI 10Way unit with dual supply isolators & 16A DP RCBO
HIGH INTEGRITY DUAL SUPPLY PV CONSUMER UNIT
NH12DSPVHI
12Way unit with dual supply isolators & 16A SP MCB
NH11DSRCBPVHI
11Way unit with dual supply isolators & 16A DP RCBO
Double Pole MCB options available on request
DUAL RCD DUAL SUPPLY PV CONSUMER UNITWITH MID
CERTIFIED GENERATION METER
CAT REF.
DESCRIPTION
NH11DSMPVDR 11Way unit with dual supply isolators & 16A SP MCB
NH6DSMPVDR
6Way unit with dual supply isolators & 16A SP MCB
NH10DSRCBMPVDR 10Way unit with dual supply isolators & 16A DP RCBO
NH5DSRCBMPVDR 5Way unit with dual supply isolators & 16A DP RCBO
DUAL RCD DUAL SUPPLY PV CONSUMER UNIT
NH12DSPVDR
12Way unit with dual supply isolators & 16A SP MCB
NH7DSPVDR
7Way unit with dual supply isolators & 16A SP MCB
NH11DSRCBPVDR 11Way unit with dual supply isolators & 16A DP RCBO
NH6DSRCBPVDR 6Way unit with dual supply isolators & 16A DP RCBO
Double Pole MCB options available on request
Note: Surge Protection devices andType B RCDs are available
on request
For PV Installation Requirements see page 60/61.
