www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
Part no.
Article no.
when ordered
separately
Price
See price
list
Std. pack
Notes
Information relevant for export to
North America
NZM2-XSTS
260156
1 set
Contains parts for two terminal locations located at top or
bottom for 3 or 4 pole switches.
Included as standard with tunnel terminal.
Degree of protection IP1X
NZM-XSTK cannot be combined with
NZM1(-4)-XIPK IP2X protection against contact with a finger.
Height or thickness of connections: 2 mm
Product StandardsUL489; CSA-C22.2 No. 5-09; IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification UL Listed, CSA certified
Suitable for
Refer to main component information
NZM-XSTK
266739
1 set
NZM2-XKSAE
119868
1 set
Contains parts for a terminal located at top or bottom for 3 or 4
pole switches.
Contact protection where cable lugs are used on screw
terminals
.
When using insulated conductor material, degree of protection
IP2X
UL/CSA certification not required
NZM2-4-XKSAE
119870
1 set
–
NZM2-XKSA
260038
1 off
Contains parts for a terminal located at top or bottom for 3 or 4
pole switches.
Contact protection where cable lugs, bars or tunnel terminals
are used.
When using insulated conductor material, degree of protection
IP1X
Product StandardsUL489; CSA-C22.2 No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
22086
CSA Class No.
1432-01
NA Certification UL Listed, CSA certified
Suitable for
Refer to main component information
NZM2-4-XKSA
266770
1 off
–
NZM2-XKP
119864
1 set
Contains parts, including insulating plate for mounting plate, for a
terminal located at top or bottom for 3 or 4 pole circuit-breakers.
Can not be combined with connection on rear NZM2(-4)-XKR.
Insulation protection up to a rated operating voltage U
e
of 415 V AC
when minimum distances are not maintained.
UL/CSA certification not required
NZM2-4-XKP
119865
1 set
–
NZM2-XKSFA
104640
1 off
Contains parts for a terminal located at top or bottom for 3 or 4
pole switches.
Enhanced contact protection (simplified finger protection).
O = for fitting at the top
U = for fitting at the bottom
UL/CSA certification not required
1 off
NZM2-4-XKSFA
104641
NZM2-XIPK
266773
1 set
Contains parts for a terminal located at top or bottom for 3 or 4 pole
switches.
Enhanced contact protection to IP2X.
Protection on grasping terminal chamber when connecting cables
in box terminals.
With two conductors maximum cross-section 25 mm
2
or AWG4.
Can not be combined with control cable terminal NZM-XSTK.
UL/CSA certification not required
NZM2-4-XIPK
266774
1 set
–
NZM2-XIPA
266777
1 set
Contains parts for a terminal located at top or bottom for 3 or 4
pole switches.
Enhanced contact protection to IP2X.
When fitting to NZM2-..-(C)NA or
NZM...-NA:
With 2 conductors maximum cross-section 25 mm
2
or AWG4.
UL/CSA certification not required
NZM2-4-XIPA
266778
1 set
–
KS150-NZM7
059777
3 off
Contains a cable lug for 3 or 4 pole switch.
Special cable lug, narrow style
–
KS120-NZM7
059776
KS95-NZM7
059775
NZM2-XKS185
260032
