www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
Part no.
Article no.
when ordered
separately
Price
See price
list
Std. pack
Notes
Information relevant for export to North America
NZM1-XSTS
260150
1 set
Contains for two terminal locations located at top
or bottom for 3 or 4 pole circuit-breakers.
Included as standard with tunnel terminal.
Degree of protection IP1X
Height or thickness of connections: 2 mm
Product Standards
UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
Suitable for
Refer to main compo-
nent information
NZM-XSTK
266739
1 set
Contains for two terminal locations located at top
or bottom for 3 or 4 pole circuit-breakers.
cannot be combined with NZM1(-4)-XIPK IP2X
protection against contact with a finger.
Degree of protection IP1X
Height or thickness of connections: 2 mm
NZM1-XKSFA
100780
1 off
Contains parts for a terminal located at top or
bottom for 3 or 4 pole switches.
Enhanced contact protection (simplified finger
protection).
Cannot be combined with NZM-XSTK control
circuit terminal.
UL/CSA certification not required
NZM1-4-XKSFA
100781
1 off
–
NZM1-XKSA
260021
1 off
Contains parts for a terminal located at top or
bottom for 3 or 4 pole switches.
Contact protection against direct contact where
cable lugs, bars or tunnel terminals are used.
Contained in the set with tunnel terminals and
screw terminals.
When using insulated conductor material to
degree of protection IP1X.
Product Standards
UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
Suitable for
Refer to main compo-
nent information
NZM1-4-XKSA
266741
1 off
–
NZM1-XIPK
266744
1 set
Contains parts for a terminal located at top or
bottom for 3 or 4 pole switches.
Enhanced contact protection to IP2X.
Protection when reaching into the cable
connection area with the connection of cables
in the box terminal.
Cannot be combined with NZM-XSTK control
circuit terminal.
–
NZM1-4-XIPK
266745
1 set
–
NZM1-XIPA
266748
1 set
Contains parts for a terminal located at top or
bottom for 3 or 4 pole switches.
Enhanced contact protection to IP2X.
UL/CSA certification not required
NZM1-4-XIPA
266749
1 set
–
NZM1-XKP
119862
1 set
Contains parts, including insulating plate for
mounting plate, for a terminal located at top or
bottom for 3 or 4 pole circuit-breakers.
Insulation protection up to a rated operating
voltage U
e
of 415 V AC when minimum distances
are not maintained.
Can not be combined with connection on rear
NZM1(-4)-XKR.
UL/CSA certification not required
NZM1-4-XKP
119863
1 set
–
