17/86 Circuit-breakers, switch-disconnectors
Terminals
2010 CA08103002Z-EN
Terminals
Max. cable
connection area
Number
of poles
For use with Terminal capacity Terminal capacity
Cable
Cable lugs
Terminal
capacity1) AWG/kcmil Copper strip
No. of discs ×
width × disc
thickness
Copper bar
width x
thickness
mm² mm mm
Box terminal
3 pole NZM2, PN2, N(S)2
≤ 160 A
Copper cable 1 x 10-185
2 x 4-70
1 x 12 - 350 ≧ 2 x 9 x 0.8 –
NZM2, PN2, N(S)2
> 160 A
4 pole NZM2-4, PN2-4,
N2-4
≤ 160 A
NZM2-4, PN2-4,
N2-4
> 160 A
Screw terminals
Standard equipment
3 pole NZM2, PN2, N(S)2 Copper cable
lugs
Aluminium cable
lugs
1 x 10 - 185
2 x 4 - 70
1 x 10 - 50
2 x 10 - 50
1 x 12 - 350 ≧ 2 x 16 x 0.8 ≧ 16 x 5
4 pole NZM2-4, PN2-4,
N2-4
Tunnel terminal
3 pole NZM2, PN2, N(S)2 Copper cable
Aluminium cable
1 x 16 - 185
1 x 16 - 185
Up to 240 mm²
can be
connected
depending on
the cable
manufacturer.
1 x 6 - 350 – –
4 pole NZM2-4, PN2-4,
N2-4
Rear terminal bolts
Not UL/CSA approved
When using cable lugs without NZM3(-4)-XKSA cover, they must be insulated.
– 3 pole NZM2, PN2, N2 Copper cable
lugs
Aluminium cable
lugs
1 x 10 - 185
2 x 4 - 70
1 x 10 - 50
2 x 10 - 50
– ≧ 2 x 16 x 0.8
≦ 6 x 24 x 0.5
≧ 16 x 5
≦ 20 x 5
4 pole NZM2-4, PN2-4,
N2-4
Notes 1) Up to 240 mm2 can be connected depending on the cable manufacturer.
15
18
8
o 8.5
24
20.5
NZM2 HPL17086EN
