15 / 16
15
Material/Finish
Installation/Mounting
Body: Aluminum white finish
Diffuser: PS
•
Recessed installation into a
wide range of ceiling types
•
Easy installation thanks to
an external connector box
enabling loop-in loop-out
wiring
•
Class II electrical
•
IP44
•
IK02
Specification
1500 lumens – Corridor
Ceiling height
(m)
Luminaire
Spacings (m)
Lux Level
Average (E
m
)
Uniformity
(U
o
)
UGR
2.4
1.2
1.8
2.4
3.0
3.6
310 lux
199 lux
157 lux
124 lux
105 lux
0.71
0.71
0.73
0.66
0.73
25
25
25
25
25
2.7
1.2
1.8
2.4
3.0
3.6
274 lux
183 lux
138 lux
114 lux
97.1 lux
0.68
0.68
0.72
0.65
0.72
25
25
25
25
25
3.0
1.2
1.8
2.4
3.0
3.6
266 lux
178 lux
134 lux
105 lux
89.4 lux
0.70
0.70
0.71
0.66
0.72
25
25
25
25
25
Based on a 21.6 x 2 metre corridor with 70/50/20 reflectances, a
0.80 maintenance factor and the working plane at floor level
Ordering guide
Performance guide
Description
Wt (Kg) SAP Code
Cat. No.
ZOE LED DL 110 600 840
0.25
96666088 ZO600Z4K
ZOE LED DL 160 900 840
0.40
96666089 ZO900Z4K
ZOE LED DL 210 1500 840
0.55
96666090 ZO1500Z4K
ZOE LED DL 110 600 830
0.25
96666092
ZO600Z3K
ZOE LED DL 160 900 830
0.40
96666093
ZO900Z3K
ZOE LED DL 210 1500 830
0.55
96666094 ZO1500Z3K
Lighting Control
SWITCHLITE SLDM
96019208 SLMW30W
SWITCHLITE MRE SLDM ADJ
96239855
SWITCHLITE CC PROGRAMMER
96240295
Accessories
Just Emergency PLUG&PLAY E3 Kit
96628839
Just Emergency PLUG&PLAY Self
Test E3 Kit
96628840
830–3000K, 840–4000K
225
205
25
12
Ø206 –210
155
170
23
12
Ø158 –162
120
23
12
Ø108–112
105
