13 / 16
13
Material/Finish
Installation/Mounting
Body: Polycarbonate
Diffuser: Polycarbonate
•
Suitable for wall or ceiling
mounting
•
Quick and easy installation
•
Suitable for BESA fixing
Ordering guide
Performance guide
Integral photocell & presence sensor
Lara’s integral photocell option will light from dusk till dawn.
(Operation level: approx. 20 lux ON, approx. 30 lux OFF).
Lara’s microwave sensor option will ensure that light is only
delivered when needed. The motion detection range and time
duration is fully adjustable, with the additional benefit of a
daylight sensor for illuminance levels between 2 and 50 lux.
MWS: Microwave presence sensor
BLK: black; WH: white
E3: 3 hour emergency lighting
PC: Photocell
Description
Wt (Kg)
SAP Code Cat. No.
LARA LED 250 800 840 WH
0.7
96666101 LAS800ZW4K
LARA LED 250 800 840 BLK
0.7
96666102 LAS800ZB4K
LARA LED 250 800 840 WH E3
0.9
96666103 LAS800ZWE4K
LARA LED 250 800 840 BLK E3
0.9
96666104 LAS800ZBE4K
LARA LED 300 1200 840 WH
1.1
96666105 LAL1200ZW4K
LARA LED 300 1200 840 BLK
1.1
96666106 LAL1200ZB4K
LARA LED 300 1200 840 WH E3
1.2
96666107 LAL1200ZEW4K
LARA LED 300 1200 840 BLK E3
1.2
96666108 LAL1200ZEB4K
LARA LED 300 1000 840 BEZEL TRIM WH 1.
96628900
LARA LED 250 800 840 MWS WH
0.7
96666109 LAS800ZMW4K
LARA LED 250 800 840 MWS BLK
0.7
96666110 LAS800ZMB4K
LARA LED 250 800 840 MWS WH E3
0.9
96666111 LAS800ZMEW4K
LARA LED 250 800 840 MWS BLK E3
0.9
96666112 LAS800ZMEB4K
LARA LED 300 1200 840 MWS WH
1.1
96666113 LAL1200ZMW4K
LARA LED 300 1200 840 MWS BLK
1.1
96666114 LAL1200ZMB4K
LARA LED 300 1200 840 MWS WH E3
1.2
96666115 LAL1200ZMEW4K
LARA LED 300 1200 840 MWS BLK E3
1.2
96666116 LAL1200ZMEB4K
LARA LED 250 800 840 PC WH
0.7
96666117 LAS800ZPW4K
LARA LED 250 800 840 PC BLK
0.7
96666118 LAS800ZPB4K
LARA LED 300 1200 840 PC BLK
1.1
96666119 LAL1200ZPB4K
LARA LED 300 1200 840 PC WH
1.1
96666120 LAL1200ZPW4K
Accessories
LARA BEZEL TRIM SMALL 250 WH
0.2
96666121 LASBEZW
LARA BEZEL TRIM LARGE 300 WH
0.2
96666122 LALBEZW
LARA BEZEL TRIM SMALL 250 BLK
0.2
96666123 LASBEZB
LARA BEZEL TRIM LARGE 300 BLK
0.2
96666124 LALBEZB
LARA EYELID TRIM SMALL 250 BLK
0.2
96666125 LASEYEB
LARA EYELID TRIM LARGE 300 BLK
0.3
96666126 LALEYEB
LARA EYELID GRILLE TRIM SMALL 250 BLK 0.2
96666127 LASEYEGRIB
LARA EYELID GRILLE TRIM LARGE 300 BLK 0.3
96666128 LALEYEGRIB
LARA GRILLE TRIM SMALL 250 BLK
0.2
96666129 LASGRIB
LARA GRILLE TRIM LARGE 300 BLK
0.3
96666130 LALGRIB
LARA Tamperproof Screw Kit
96628612 LAVPSKIT
Lighting Control
SWITCHLITE MRE SLDM ADJ
96239855 SLMW30W
SWITCHLITE SLDM
96019208
SWITCHLITE CC PROGRAMMER
96240295
800 lumens – Corridor
1200 lumens – Corridor
Ceiling height
(m)
Luminaire
Spacings (m)
Lux Level
Average (E
m
)
Uniformity
(U
o
)
UGR
2.4
3.0
2.4
1.8
63 lux
80 lux
101 lux
0.66
0.74
0.71
25
25
25
2.7
3.0
2.4
1.8
58 lux
70 lux
93 lux
0.66
0.71
0.70
25
25
25
3.0
3.0
2.4
1.8
54 lux
68 lux
91 lux
0.66
0.72
0.71
25
25
25
Ceiling height
(m)
Luminaire
Spacings (m)
Lux Level
Average (E
m
)
Uniformity
(U
o
)
UGR
2.4
3.0
2.4
1.8
92 lux
117 lux
162 lux
0.64
0.73
0.74
25
25
25
2.7
3.0
2.4
1.8
85 lux
108 lux
150 lux
0.63
0.72
0.65
25
25
25
3.0
3.0
2.4
1.8
82 lux
104 lux
130 lux
0.66
0.72
0.55
25
25
25
Based on a 21 x 2 metre corridor with 70/50/20 reflectances,
a 0.80 maintenance factor and the floor as the working plane.
Eylid trim
Bezel trim WH
Bezel trim BLK
Grille trim
Eylid grille trim
Ø300
68
Ø250
68
