Installation
For LED Luminaires without a
DC jack:
The input lead of the luminaire
and the output lead of the
driver may be stripped, so the
emergency module output
can be connected in-line
via a junction box. An
additional connection
lead with tails is
provided.
Wiring
Junction Box
Class III
LED
Luminaire
Switched Supply
220-240Vac
Un-Switched Supply
220-240Vac
Universal Emergency Module
LED Indicator
LED
Driver
Connection
Lead
