31 Fire-rated downlights +44 (0)1243 838999
Cost effective fire-rated LED downlight
• Dimmable as standard
• 82.7mm depth, ideal for shallow ceiling voids
• Ultra fast press-fit termination
• Up to 88% saving against halogen
• Advanced LED chips
• 50,000 hours life
• 38° beam angle
CONSTRUCTION
Body – Pressed steel
Bezel – Die-cast aluminium
Max. void working temp. 30°C
FINISH
Brushed nickel, chrome, white
CLASSIFICATION
Class 1
IP65 | 240V | Zone 1
LED
Warm white (3000K) | CRI: Ra (80)
Cool white (4000K) | CRI: Ra (80)
3000K 4000K
CUTOUT SIZES
Ø72-74mm – 12.5mm thick
30 minute ceiling types
Ø79mm-81mm – 30mm thick
60-90 minute ceiling types
JC94301CH
JC94301WH JC94301BN
FGLED3®
CODE DESCRIPTION COLOUR TEMP. WATT** LUMENS
JC94301 FGLED3® mains dimmable Warmwhite 3W 320
JC94302 FGLED3® mains dimmable Cool white 3W 380
*10 year for domestic dwellings, 5 year for commercial properties. Requires online registration.
**LED Wattage = 3W Total Wattage = 4.8Wmax
82.7mm
92mm
121mm
10 year
Extended warranty*
Dimmable
As standard
IP65
Suitable for bathrooms
COMPATIBLE LED DIMMER
See page 238
