JCC Catalogue 30

28 / 274

28 Fire-rated downlights
The market leading fire-rated LED downlight
• Square bezel version of the FGLED6® range
• Outperforms 50W GU10 halogen
• Fully compliant with building regulations
• Six LED array provides clear, crisp light
• High quality, die-cast aluminium bezel
• 38° beam angle
CONSTRUCTION
Body – Pressed steel
Bezel – Die-cast aluminium
Max. void working temp. 30°C
FINISH
Brushed nickel, chrome, white
CLASSIFICATION
Class 1
IP65 | 240V | Zone 1
LED
Warm white (3000K) | CRI: Ra (80)
Cool white (4000K) | CRI: Ra (80)
3000K 4000K
CUTOUT SIZES
Ø72-74mm – 12.5mm thick
30 minute ceiling types
Ø79mm-81mm – 30mm thick
60-90 minute ceiling types
JC94572CH
JC94572BN JC94572WH
FGLED6 Square®
CODE DESCRIPTION COLOUR TEMP. WATT** LUMENS
JC94572 FGLED6® Square dimmable Warmwhite 6W 450
JC94573 FGLED6® Square dimmable Cool white 6W 500
JC94574 FGLED6® Square non-dimmable Warmwhite 6W 450
JC94575 FGLED6® Square non-dimmable Cool white 6W 500
JC94576 FGLED6® Square dimmable emergency Warmwhite 6W 450
JC94577 FGLED6® Square dimmable emergency Cool white 6W 500
JC94578 FGLED6® Square non-dimmable emergency Warmwhite 6W 450
JC94579 FGLED6® Square non-dimmable emergency Cool white 6W 500
*10 year for domestic dwellings, 5 year for commercial properties. Requires online registration.
**LED Wattage = 6W Total Wattage = 7.2Wmax
113mm
6.5mm
92mm
Emergency
Versions available
10 year
Extended warranty*
Dimmable
Option
IP65
Suitable for bathrooms
98mm
COMPATIBLE LED DIMMER
See page 238
