Shallow Flush Floor
Ref.SSF
Shallow flush floor trunking is designed for a minimal screed
application. It is also available for wooden floors were the same
principle applies.
Width and height to customer specification.
Floor Trunking Tray Cover
Ref.FFR
The trunking body and tray type cover are formed from galvanised
sheet steel. The standard depth of the tray cover is 8mm but deeper
sections for wood block flooring etc are available. Dividing fillets are
fitted to 150mm and wider in order to support cover.
When ordering multi-compartment floor trunking the width of each
compartment should be specified. Any sizes available to order.
Floor Trunking Chequer Plate Cover
Ref.FFC
The trunking body is similar to tray type. A self adhesive
gasket is fitted under the chequer plate cover which can
be supplied either galvanised or in grey enamel finish
also available with chequer plate lid.
When ordering multi-compartment floor trunking, the
width of each compartment should be specified. Any sizes
available to order.
Cavity Floor Access Hatch
Ref.CAVHATCH
This bespoke hatch, fitted at finished floor level, allows access to
services within a cavity floor system. Cutouts to allow cables can be
supplied to your specification.
Special
Floor Box - Metal Trim
This metal trim can be Polyester Powder Coated or manufactured in Stainless Steel
for installation into standard inspection and service outlets, across the full floor
system ranges.
Available with 7mm, 9mm, 15mm, 20mm & 25mm tile recess.
INNOVATIVE DESIGN SOLUTIONS
Product Finishing Key (See page 24)
