DADO TRUNKING
UNITRUNK DADO TRUNKING
is available with all the necessary bends etc to form a complete installation.
The body and divider of the DAD-TK are manufactured from galvanised sheet steel to BS EN 50085-1 :2005 plus BS
EN50085-2-1 :2006. The dividers are provided with 20mm E knockouts for easy access to all compartments at 200mm
centres. A Back Box is also available on request for complete segregation. All trunking is supplied in 3 metre lengths
as standard, complete with joining plates and screws.
The cover is made from 1.2mm hot dip galvanised sheet steel and can be finished in epoxy polyester coating of any
colour on request. The trunking is suitable for carrying mains, telephone and VDU or other low voltage circuits.
It is normal practice to run the mains circuit in the larger compartment as the cover can be punched to accept a
standard 13 amp socket or other accessory.
Alternatively a short section of cover can be supplied with a one or two gang socket outlet. Socket plates and
accessories are manufactured to overlap at the edges of the trunking cover.
Dado Trunking
Ref. DADTK62 - Single Compartment (152mmx51mm)
Ref. DADTK62x3 - 3 Compartment (152mmx51mm)
Ref: DADTK82 - Single Compartment (202mmx51mm)
Ref: DADTK82x3 - 3 Compartment (202mmx51mm)
Other sizes available on request.
Dado Tee
Dado Blank End
Ref. DADBE62 - (152mmx51mm)
Ref. DADBE82 - (202mmx51mm)
152mm
202mm
51
mm
51
mm
Ref. DADT62 - Single Comp.
Ref. DADT62x3 - 3 Comp.
Ref: DADT82 - Single Comp.
Ref: DADT82x3 - 3 Comp.
BENCH OUTLET BOXES & PERIMETER TRUNKING
Product Finishing Key (See page 24)
