The Big Unitrunk Product Guide V4

127 / 162

For use with UFUF12.
For use with UFUF9.
Service Outlet (PVC Trim)
Ref. CT/S 3
Ref. CT/S 43
For use with UFUF69.
Underfloor Blank End
Ref. UFBE
Underfloor Coupling
Ref. UFTC
Flange Coupling
Ref. UFFC
Adjustable Collar
(For Under Floor) Universal Fitting 9 & 12
Riser Flange
Ref.UFRF
Riser Bend
Ref.UFRB
25mm 130mm
38mm 142mm
Trunking height URFB height (H)
Depth of screed should also
be quoted when ordering.
Riser Bend
(From underfloor
into skirting trunking)
Ref.UFST
Depth of screed should also
be quoted when ordering.
Depth of screed should also
be quoted when ordering.
1 off supplied/ 3m length.
Height can be manufactured to suit customer requirements.
Please specify screed depth and adjustable range required when ordering.
Underfloor Trunking
Ref. UF
Supplied in 3m lengths
as per adjacent table
See Page 129
Inspection Lid
For use with UFUF12.
For use with UFUF9.
Ref. CT/13
Ref. CT/143
Supplied with a 7mm recess & PVC Trim. Stainess Steel Trim & Deeper
recesses are available (Made to order)
Supplied with a 7mm recess & PVC Trim. Stainess Steel Trim & Deeper
recesses are available (Made to order)
127
visit online: uk ireland
UNDERFLOOR (IN SCREED) TRUNKING SYSTEMS
