Unitrunk Intelok Channel is a strong, easy to erect support system, ideal for
supporting cable trays, cable ladders, pipes and ducting and is adaptable for use
in many other applications. The flanges on Intelok channel are serrated to give
improved slip resistance over that of conventional ‘strut’ systems, particularly
when Intelok channel nuts are used.
Intelok channels are made in deep, shallow and multiple combination profiles. Standard lengths
are either
3
or
6
metres, with other lengths available to order. When used with our extensive
range of brackets, an infinite variety of frameworks and structures can be created. Intelok channels
conform to
BS6946
.
SECTION 7
CHANNEL & SUPPORT
SYSTEMS
ACCREDITED TO THE FOLLOWING STANDARDS
LUL ACCREDITATION ID:
1822
Unitrunk Intelok Channels are supplied in the following
finishes
STRAIGHT CHANNEL
GM
Hot dip galvanized Structural Steel
(Steel BS EN 10025-2 and Galvanising BS EN
1461
:
2009)
Pre-Galvanised Structural Steel (Steel BS EN 10326
)
BRACKETS
GA
Hot dip galvanized Mild Steel (Steel BS EN 10111 /
BS EN 10130 and Galvanising BS EN
1461
:
2009)
STRAIGHT CHANNEL & BRACKET
SS
Stainless steel grade
1
.
4404
(
316
marine) to BS EN
10088-2
:
2005
The safe loading figures are based on
a) The x-x axis
b) A simply supported beam
c) Pre-galvanised steel - yield
250
N/mm
2
d) A safety factor of
1.6
against yield
