2 / 4
C-TEC’s FP Range of
conventional fire alarm
control panels is one of
the most robust and
cost-effective available.
Fully compliant with
BS 5839 part 4, the range encompasses no less than ten
different variants, covering 1 to 14 zones.
The size, durability and flexibility of the range makes it ideal for use in
all types of commercial and residential property including small shops,
factories, schools, warehouses, offices and houses in multiple occupation.
Often referred to as ‘the installer’s choice’, easy-to-follow wiring
instructions are printed adjacent to the terminals of all variants and a
lift-off lid guarantees an easy first fix and straightforward maintenance.
The panel’s broad compatibility with virtually all known smoke and heat
detector ranges and its ability to interpret a short circuit in any zone(s)
as a fire or fault condition make it particularly useful for retro-installations.
An optional head removal facility (which utilises C-TEC’s BF378 range
of end-of-line monitoring units) is also available, making the FP fully
compliant with the head removal requirements of BS 5839 part 1.
FP Range Features
Fully compliant with BS 5839 Part 4
Lift-off lid for easy first fix and maintenance
Attractive easy-to-clean polycarbonate front label
Heavy-duty base connections
Robust metal lid and metal back box
Ultra-bright, long-life LED indicators
Built-in 24V power supply and battery charger
Optional head removal facility for compliance
with BS 5839 Part 1
Compatibility with virtually all known
conventional smoke and heat detector ranges
True three wire operation of sounder and
detector circuits (Ov is common) for
considerable cost savings on installation
Separate indicators for open and short circuit
fault, sounder fault and battery/power supply
fault
Non-latching ‘class change’ sounder input,
latching fire and non-latching fault outputs
(available via optional expansion loom)
Fault buzzer mute facility
Space available for the rated capacity
of VRLA batteries
Short circuit = fire facility (pre-1980 BS, no
resistors in call points), selectable on a zone by
zone basis for retro-installations
True battery monitoring circuit
One man walk test and zone isolate facility
(not available on EFP1)
Ancillary connections for repeater panels and
other system add- including fault relay
modules, fire relay modules, sounder delay
relay modules, sounder extender kits, etc
(not available on EFP1)
Easy to follow installation instructions
and log book
Multilingual variants available (subject to
quantities)
of 1-14 ZONE
CONVENTIONAL
FIRE ALARM
CONTROL PANELS
