With the growing emphasis on safeguarding property as well as
people, the market for automatic fire suppression systems is
booming. The EP203 three zone automatic extinguisher panel from
C-TEC has been specifically designed to meet this demand.
Third-party approved to EN 12094 part 1 (Fixed Firefighting Systems -
Components for Gas Extinguishing Systems) and EN54 parts 2 & 4 by the
LPCB, the panel epitomises quality, durability and reliability and is ideal for
use in any area housing expensive, dangerous or irreplaceable items of equipment.
Featuring an intuitive 128 x 64 pixel two-colour graphic display that gives clear and concise feedback to the user,
installer and commissioning engineer, the panel also includes six monitored inputs (including hold and abort), a time
stamped log, adjustable flood times and volt-free changeover relays for fire, local fire, 1st stage active, 2nd stage active,
extractor fan and fault.
The panel is supplied in an elegantly styled, durable enclosure with all of its electronics - apart from its powerful 3A EN54-4
switch mode PSU - mounted on a detachable metal bridge plate for ease of installation. A wide range of ancillaries are also
available including remote status units, hold-off and abort buttons, line terminators and output expansion relay boards.
!
LPCB approved to EN 12094 part 1 and EN54 parts 2 & 4
!
Functions as a standard three zone fire panel with
additional circuitry for controlling the release of
fire-suppressing gas into protected areas
!
Unique 128 x 64 pixel graphical display facilitates
straightforward system programming
!
Any combination of activated zones can be
programmed to automatically start the panel’s
extinguishant release sequence
!
Includes a pull-down front-panel manual release
button and two keyswitches for accessing the panel’s
functions and toggling between auto/manual mode
!
Three conventional sounder circuits (two x 1st
stage, one x 2nd stage)
!
Powerful 3A EN54-4 compliant switch mode PSU
!
Low quiescent current - less than 40mA on mains fail
!
Wide range of monitored inputs and
auxiliary outputs (see schematic)
!
Abort and hold inputs allow the panel’s release
sequence to be cancelled or suspended at any time
!
Time-stamped event log
!
RS485 connections for up to eight flush or surface
remote status units with their own LCDs, manual release
and mode (auto/manual) switches. Single gang economy
status units (without an LCD) are also available.
!
Extensive range of commissioning and engineering
functions
!
Optional relay expansion boards and single gang abort
and hold buttons
!
Ideal for use in computer rooms, telecommunication
centres, archive storage areas, chemical plants, generator
rooms, museums, etc..
!
System line terminator included with all panels
