Earth bonds & clamps
Flexible circular copper braid bond
Length
A A
CBB-16-200-9
Flexible copper or flexible tinned copper braid terminated with pressed
terminal lug at each end, suitable for bonding gates, doors, fences etc.
Pressed terminal lug connection ensures maximum electrical contact with
minimum earth resistance.
Standard braid sizes are shown. Braids are available in other sizes, lengths,
materials or terminations to special order.
BS EN 13602
Overall braid
diameter
Length Hole
diameter (A)
Cross-sectional
area
Weight Part
each No.
Copper braid
4.2 mm 200 mm 7 mm 6 mm2 0.01 kg CBB-6-200-7
4.2 mm 400 mm 7 mm 6 mm2 0.02 kg CBB-6-400-7
5.4 mm 200 mm 7 mm 10 mm2 0.02 kg CBB-10-200-7
5.4 mm 400 mm 7 mm 10 mm2 0.04 kg CBB-10-400-7
7 mm 200 mm 9 mm 16 mm2 0.03 kg CBB-16-200-9
7 mm 400 mm 9 mm 16 mm2 0.06 kg CBB-16-400-9
8.5 mm 200 mm 11 mm 25 mm2 0.05 kg CBB-25-200-11
8.5 mm 400 mm 11 mm 25 mm2 0.10 kg CBB-25-400-11
11.5 mm 200 mm 11 mm 50 mm2 0.10 kg CBB-50-200-11
11.5 mm 400 mm 11 mm 50 mm2 0.20 kg CBB-50-400-11
14.5 mm 200 mm 13 mm 70 mm2 0.13 kg CBB-70-200-13
14.5 mm 400 mm 13 mm 70 mm2 0.25 kg CBB-70-400-13
16 mm 200 mm 13 mm 95 mm2 0.19 kg CBB-95-200-13
16 mm 400 mm 13 mm 95 mm2 0.37 kg CBB-95-400-13
Tinned copper braid
4.2 mm 200 mm 7 mm 6 mm2 0.01 kg CBB-6-200-7-T
4.2 mm 400 mm 7 mm 6 mm2 0.02 kg CBB-6-400-7-T
5.4 mm 200 mm 7 mm 10 mm2 0.02 kg CBB-10-200-7-T
5.4 mm 400 mm 7 mm 10 mm2 0.04 kg CBB-10-400-7-T
7 mm 200 mm 9 mm 16 mm2 0.03 kg CBB-16-200-9-T
7 mm 400 mm 9 mm 16 mm2 0.06 kg CBB-16-400-9-T
8.5 mm 200 mm 11 mm 25 mm2 0.05 kg CBB-25-200-11-T
8.5 mm 400 mm 11 mm 25 mm2 0.10 kg CBB-25-400-11-T
11.5 mm 200 mm 11 mm 50 mm2 0.10 kg CBB-50-200-11-T
11.5 mm 400 mm 11 mm 50 mm2 0.20 kg CBB-50-400-11-T
14.5 mm 200 mm 13 mm 70 mm2 0.13 kg CBB-70-200-13-T
14.5 mm 400 mm 13 mm 70 mm2 0.25 kg CBB-70-400-13-T
16 mm 200 mm 13 mm 95 mm2 0.19 kg CBB-95-200-13-T
16 mm 400 mm 13 mm 95 mm2 0.37 kg CBB-95-400-13-T
NEW
