63 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
2/49
2
Non-metallic conduit systems
PVC Type XF & RF - Xtraflex / RF
PVC Type XF - Xtraflex
Standard Weight Conduit
/
Materials:
PVCu Spiral with Plasticised PVC Covering /
Colour:
Black (BL) Only
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
XF12
12mm
14.5mm
10mm
25mm
30m
XF16
16mm
16.5mm
12mm
30mm
30m
XF20
20mm
20.5mm
16mm
35mm
30m
XF25
25mm
27.5mm
22mm
50mm
30m
XF32
32mm
33.5mm
28mm
60mm
30m
XF40
40mm
44.0mm
38mm
80mm
30m
XF50
50mm
57.5mm
50mm
105mm
30m
To order quote part number & reel length, e.g. XF16/30M
Type XF
Standard Weight Conduit
PVC Type RF - RF
Heavyweight Conduit - Smooth Bore
/
Materials:
PVCu Spiral with Plasticised PVC Covering
Colour:
Black (BL), Grey (GR)
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
RF12
12mm
14.5mm
10mm
25mm
30m
RF16
16mm
16.5mm
12mm
30mm
30m
RF20
20mm
20.5mm
16mm
35mm
30m
RF25
25mm
27.5mm
22mm
50mm
30m
RF32
32mm
33.5mm
28mm
60mm
30m
To order quote part number, colour & reel length, e.g.RF16/BL/30M
Approvals
Type RF
Heavyweight Conduit
Smooth Bore
Approvals
IP Rating
Appropriate Fitting
For use with:
Type XF
IP40
N/A
IP65
Type XF
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -5ºC to +60ºC
Moving Applications: -5ºC to +60ºC
Flexibility & Fatigue Life
Very High Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
High
IP Rating
Appropriate Fitting
For use with:
Type RF
IP40
N/A
IP65
N/A
IP66
N/A
IP67
Type RF
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -20ºC to +60ºC
Moving Applications: -5ºC to +60ºC
Flexibility & Fatigue Life
Medium Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
High
