Cable glands & terminal blocks
Type 6012 & 10012 polyamide - terminal blocks
Type 10012 Polyamide - Terminal Block
10mm
2
Polyamide Terminal Blocks
Materials:
Polyamide 6, Galvanised Brass Inserts & Galvanised Steel Screws /
Colour:
White
Wire
Pack
Part No.
Base
Protector
‘T’ Insert
No. Poles
Width A
Height B
Rating
Quantity
10012/1001
RAISED
Yes
12 Pole
180mm
28mm
45A
10
10012L
LEVEL
12 Pole
180mm
22mm
45A
10
10012L/1001
LEVEL
Yes
12 Pole
180mm
22mm
45A
10
10012LT
LEVEL
12 Pole
180mm
22mm
45A
10
10012T
RAISED
12 Pole
180mm
28mm
45A
10
10012
RAISED
12 Pole
180mm
28mm
45A
10
Nominal Clamping Area
10mm
2
Approvals
Flammability
UL94 - V2 (Nylon material)
Fire Performance
Halogen Free
Type 10012 terminal block
Max Ambient Temp
85ºC
Nominal Voltage
450V
Dimensions
Type 6012 Polyamide - Terminal Block
6mm
2
Polyamide Terminal Blocks
Materials:
Polyamide 6, Galvanised Brass Inserts & Galvanised Steel Screws /
Colour:
White
Wire
Pack
Part No.
Base
Protector
‘T’ Insert
No. Poles
Width A
Height B
Rating
Quantity
6012/601E
Raised
Yes
12 Pole
133.7mm
20.8mm
32A
25
6012TE
Raised
Yes
12 Pole
133.7mm
20.8mm
32A
25
6012L/601E
Level
Yes
12 Pole
133.7mm
19.3mm
32A
25
6012LE
Level
12 Pole
133.7mm
19.3mm
32A
25
Nominal Clamping Area
6mm
2
Approvals
Flammability
UL94 - V2 (Nylon material)
Fire Performance
Halogen Free
Type 6012 terminal block
Max Ambient Temp
85ºC
Nominal Voltage
450V
Dimensions
