Adaptaflex Product Catalogue |
LIT211GB 0715
6
Index Claw - Cable Gland
High Performance IP68 Cable Gland
Materials:
Polyamide 6.6 with Nitrile Rubber Seal /
Colour:
Black RAL 9005 (B)
Metric
Thread
Cable Max Cable Min
Gland
Gland
Across Flats Pack
Sealing
Locknut
Part No.
Thread A
Lengths B
Diameter
Diameter
Depth C
Diameter D Dimension E Quantity
Washer
Part No.
211-9020
M16
15mm
9mm
5mm
24mm
26mm
24mm
50
96
92-B
211-9060
M20
15mm
11mm
7mm
25mm
30mm
27mm
50
97
93-B
211-9140
M20
15mm
16mm
12mm
26mm
35mm
32mm
50
97
93-B
The Index Claw Gland is suitable for many applications where cables are subject to high tensile loads. Typical applications would range from portable equipment such as
generators to highly mobile factory equipment. The performance of the Index Claw Gland allows for IP68 rating at 5 bar and cable anchorage of 15.9kgs
IP Rating
IP68
Yes (5 bar 30min)
Approvals
Cable glands & terminal blocks
Index Claw - cable gland
Temperature Range
Static Applications: -20ºC to +90ºC
Key Features
– Ideal for general use
– IP68 Protection (5 bar 30mins)
– Metric
Flammability
UL94 - V2 (Nylon material)
Halogen Free
Yes
Index Claw Cable Gland
E
D
A
B
C
Dimensions
