Product Selection
MCCB Panelboard metering in 6 easy steps.......
Panelboard Plug In Metering
Note:- All active energy meters require a minimum loading to operate correctly. Always select a CT scaling range representative of the likely full
load maximum current. For advise, call our technical support team on 0843 22 753 88
Step 1: Select Panelboard
Description
250A Panelboard
400A Panelboard
630A Panelboard
4 Way MCCB Panelboard
PSPB254
-
-
6 Way MCCB Panelboard
PSPB256
PSPB406
PSPB636
8 Way MCCB Panelboard
PSPB258
-
PSPB638
12 way MCCB Panelboard
PSPB2512
PSPB4012
PSPB6312
18 way MCCB Panelboard
-
PSPB4018
-
Step 4: Select Incoming Meter Pack or Kit
Description
Part Nos
250A Meter Pack (bottom connection only)
PSPBS250MP
400A Meter Pack (bottom connection only)
PSPBS400MP
630A Meter Pack (bottom connection only)
PSPBS630MP
or
250A Plug and Play Incoming Meter Kit (fits into bottom meter position of side ext box)
PSPBS250SW
400A Plug and Play Incoming Meter Kit (fits into bottom meter position of side ext box)
PSPBS400SW
630A Plug and Play Incoming Meter Kit (fits into bottom meter position of side ext box)
PSPBS630SW
Step 5: Select Outgoing meter kit (1 per metered circuit)
Description
Part Nos
63A Plug and Play Outgoing Meter Kit (including CT, meter and plug-in loom)
PSPBL63SW
125A Plug and Play Outgoing Meter Kit (including CT, meter and plug-in loom)
PSPBL125SW
160A Plug and Play Outgoing Meter Kit (including CT, meter and plug-in loom)
PSPBL160SW
250A Plug and Play Outgoing Meter Kit (including CT, meter and plug-in loom)
PSPBL250SW
Step 3: Select Meter Side Extension Box
Description
250A Panelboard
400A Panelboard
630A Panelboard
4 Way Meter Side Extension Box
PSPB25EXM4
-
-
6 Way Meter Side Extension Box
PSPB25EXM6
PSPB40EXM6
PSPB63EXM6
8 Way Meter Side Extension Box
PSPB25EXM8
-
PSPB63EXM8
12 Way Meter Side Extension Box
PSPB25EXM12
PSPB40EXM12
PSPB63EXM12
18 Way Meter Side Extension Box
-
PSPB40EXM18
-
Step 2: Select Incoming Device
Description
250A Panelboard
400A Panelboard
630A Panelboard
160A 3P Circuit Breaker Switch
PSFN3160CB
-
-
200A 3P Circuit Breaker Switch
PSFN3200CB
-
-
250A 3P Circuit Breaker Switch
PSFN3250CB
PSCH3250CB
PSCH3250CB
320A 3P Circuit Breaker Switch
PSCH3320CB
PSCH3320CB
400A 3P Circuit Breaker Switch
PSCH3400CB
PSCH3400CB
630A 3P Circuit Breaker Switch
PSCH3630CB
160A 3P MCCB
PSFN3160MC
-
-
200A 3P MCCB
PSFN3200MC
-
-
250A 3P MCCB
PSFN3250MC
PSCH3250MC
PSCH3250MC
320A 3P MCCB
-
PSCH3320MC
PSCH3320MC
400A 3P MCCB
-
PSCH3400MC
PSCH3400MC
630A 3P MCCB
-
-
PSCH3630MC
Step 6: Select accessories if required
Description
Part Nos
Meter Extension Loom to bypass 3 meters (0.9m)
PSPBSW3ME
Meter Extension Loom to bypass 5 meters (1.2m)
PSPBSW5ME
Spare Standard Wiring Loom
PSPBSWCK
