Panelboard Plug In Metering
Easy meter installation in minutes...
Havells Switchgear launches a new range of energy meters incorporating plug and play technology which eliminates wiring errors and
dramatically reduces installation time.
PowerSafe Panelboard is
pre-fitted with 50kA in-line
fuses for ease of installation
and increased electrical safety
Meters are self powered -
jump cables facilitate looping
of supply between meters
Meters have both pulse and
serial communication outputs
providing universal integration
with BMS and EMS Systems
Meter CT ratios are pre-set to
eliminate programming errors
Surge protection ready side
extension boxes eliminates
installation variables. Window
available for easy viewing
Incoming meter pack is
pre-configured ready to connect
CTs are reversible and clearly
labelled and also feature
internal ground facility.
Havells Quikwire plug-in metering solution for MCCB panelboards is
designed to utilise side extension boxes to facilitate mounting of meters
for both outgoing and incoming circuits.
MCCB Panelboards are ready with meter supply and the side extension
chambers are supplied with meter cut outs and fitted with removable
blanking pieces. Plug-in meters, current transformers and harnesses
have been specifically engineered to compliment the MCCB panelboard
to ensure meter installation is quick and easy.
Other Features
• Simple catalogue references for easy ordering (1 cat no. per
metered circuit)
• Pull resistance connectors ensure long term system integrity
• Incoming meter packs are available for applications where only
the supply is to be metered and where no side extension
chambers are required
