Ethernet Devices
TAC Xenta 700 Controller
The TAC Xenta 700 series is a multifunctional presentation and control systemwith an
embedded web server that allows you to access your control application and control
networks via a web browser - anywhere in the world, at any time. TAC Xenta 700 series
controllers are the first to combine building automation, web functionality, alarm handling
and amazing graphics, all in a powerful, compact package. This all-in-one solution has
everything you need to monitor and control your settings in a single economical device.
Furthermore, Xenta 700 controllers are Xenta servers designed to be connected via TCP/IP
to TAC Vista in larger installations, aggregating data for easy operation and benchmarking.
All functions for daily operations such as Alarm Handling, Trend Logging and Viewing,
Event Handling, Time Schedules, Advanced Dynamic Graphics, are included. The TAC
Xenta 700 series comprises four controllers, as per the table below.
FUNCTIONAL FEATURES
•
TAC Xenta 700 controller
family with built-in web
functionality
•
Configurable or automatically
generated Web interface
•
Complete web-based Building
Management System
•
Highly scalable systems
based on TAC Xenta 700 in
combination with TAC Vista
•
IP connectivity enabling
worldwide access via the
Internet
•
Versatile and easily learnt TAC
Menta programming tool
•
Several TAC Menta
applications can run
simultaneously
•
Multiple instances of one TAC
Menta application for easy
engineering
•
High performance control
applications
•
Efficient engineering based on
the TAC XBuilder tool
•
Security functions for TCP/IP
firewalls
•
Complete alarm handling
capability
•
Dynamic color graphics
(updated automatically)
•
Flexible value displays - in
diagrammatic or tabular form
•
Data logging and data logging
viewer
SPECIFICATIONS
Operating voltage . . . . . . . . . . . . 24 V AC ±20%, 50/60 Hz or 19–40 V DC
Power consumption . . . . . . . . . . . max 5 W
Transformer sizing . . . . . . . . . . . . 5 VA
Dimensions. . . . . . . . . . . . . . . . . . 90 x 110 x 77mm (3.5” x 4.3” x 3”)
Enclosure rating . . . . . . . . . . . . . . IP 20
Real Time Clock
Accuracy at +25°C (77º F) . . . . . . ±12 minutes per year
Power failure protection. . . . . . . . 72 h
Ambient Temperature
Storage. . . . . . . . . . . . . . . . . . . . . –20°C to +50°C (–4°F to +122°F)
Operation . . . . . . . . . . . . . . . . . . 0°C to +50°C (+32°F to +122°F)
Humidity . . . . . . . . . . . . . . . . . . . max. 90% RH non-condensing
Communication
A: RS232 . . . . . . . . . . . . . . . . . . . 2400 – 57600 bps, RJ45, 8-p
A: RS485 . . . . . . . . . . . . . . . . . . . 2400 – 57600 bps, async. terminal block
B: RS232 . . . . . . . . . . . . . . . . . . . RJ10, 4-p
C: RS485 (Xenta 731) . . . . . . . . . sync. (SDLC) terminal block
L
ON
W
ORKS
®
. . . . . . . . . . . . . . . . . . TP/FT-10, terminal block
Ethernet . . . . . . . . . . . . . . . . . . . . TCP/IP, 10Base-T, RJ45
DESCRIPTION
0-073-0150-0 El.Part TAC Xenta 701
TCP/IP based controller
0-073-0155-0 El.Part TAC Xenta 711
TCP/IP based controller, end-user web
0-073-0160-0 El.Part TAC Xenta 721
TCP/IP based controller
0-073-0165-0 El.Part TAC Xenta 731
TCP/IP based controller, end-user web
ACCESSORIES
0-073-0902 Terminal part TAC Xenta 400.
0-073-0920 TAC Xenta: Programming Serial Kit
Supports Modbus MicroNet
I/NET
Web
I/O
Modules
Xenta
280/300/401
Xenta 701
Service
10
XENTA 711
Custom 10
T
Xenta 721
Service
20
T
Xenta 731
T T
T
Custom 20
T
Service - web pages generated automatically for commissioning and service purposes only. No end-
user web content available.
Custom - totally configurable end-user web pages available.
