Ethernet Devices
TAC Xenta 527
The TAC Xenta 527 is a comprehensive presentation system, which enables
secure web access to both TAC I/NET Seven and TAC Vista
TM
networks
simultaneously. It provides you with the freedom to monitor your system
from any location with Internet access. With automatic network discovery of
TAC I/NET systems, the only configuration needed is to point the Xenta 527
to TAC I/NET’s NetPlus
TM
Routers or TAC I/NET Hosts. After that, your entire
TAC I/NET network is immediately available through the web interface.
You can access any point in your system, either through the convenient
browse functionality, or via a graphic page link. Comprehensive control
features include changing values such as set points, optimization parameters,
and PID parameters. Manual control features such as test, hold, and manual
are all supported as well as acknowledge, and momentary release for doors.
FUNCTIONAL FEATURES
•
Real time graphics and
dynamic data
•
Simultaneous presentation
of TAC I/NET and TAC Vista
systems
•
Trend logging and analysis
•
Time scheduling
•
Time synchronization
•
Alarm management
•
Alarm notification via email
•
Device mode management
•
Event viewing and filtering
•
Point control
•
Operator security
•
Personal home page
•
Wireless Sensor Support
•
Embedded Net Plus router
•
Peer to Peer linking of TAC
I/NET to LON
®
signals
•
Configurable Encryption
for TAC I/NET I/P
communications
•
Supports DNS and DHCP
configurations
•
Comprehensive SNMP
integration
•
On-board Controller LAN
connection
SPECIFICATIONS
Dimensions. . . . . . . . . . . . . . . .90 x 110 x 77mm (3.5” x 4.3” x 3.0”)
Supply voltage . . . . . . . . . . . . .24 V AC ±20%, 50/60 Hz or 19–40 V DC
Power consumption . . . . . . . . .max. 5 W
Transformer sizing . . . . . . . . . .5 VA
Ambient Temperature
Storage. . . . . . . . . . . . . . . . . . . –20 °C to +50 °C (–4 °F to +122 °F)
Operation . . . . . . . . . . . . . . . .0 °C to +50 °C (+32 °F to +122 °F)
Humidity . . . . . . . . . . . . . . . . .max. 90% RH non-condensing
Mechanical
Dimensions. . . . . . . . . . . . . . . .90 x 110 x 77mm (3.5” x 4.3” x 3”)
Weight . . . . . . . . . . . . . . . . . . .0.2 kg (0.44 lb.)
Enclosure rating . . . . . . . . . . . .IP 20
Real Time Clock
Accuracy at +25 °C (77°F) . . . .±12 minutes per year
Power failure protection. . . . . .72 h
Communication
A: RS232 . . . . . . . . . . . . . . . . .2400 – 57600 bps, RJ45, 8-p
A: RS485 . . . . . . . . . . . . . . . . .2400 – 57600 bps, async. terminal block
B: RS232 . . . . . . . . . . . . . . . . .RJ10, 4-p
C: RS485 . . . . . . . . . . . . . . . . .sync. (SDLC) terminal block
L
ON
W
ORKS
®
. . . . . . . . . . . . . . . .TP/FT-10, terminal block
Ethernet . . . . . . . . . . . . . . . . . .TCP/IP, 10Base-T, RJ45
Memory
Internal memory. . . . . . . . . . . .16 MB
External memory . . . . . . . . . . .expandable with MMC
(4 – 128 MB, MMC card)
DESCRIPTION
0-073-0820-0 TAC Xenta 527
ACCESSORIES
0-073-0902-0 Terminal part TAC Xenta 400
0-073-0920-0 TAC Xenta: Programming Serial Kit
