TGML is the enhanced Vista graphics system. The editor
for TGML graphics provides the user with the most pow-
erful and easy-to-use operator interface in the industry.
The richness and flexibility of what can be achieved is
unrivalled.
In addition to the ability to draw basic shapes like lines,
polylines, curves, polygons, ellipses, arcs etc, the list of
functions includes:
•
Components and symbols. Use the symbols supplied
with TGML, e.g. DIN and ISO, or create your own
library with your preferred look and feel.
•
Windows standard user interface ‘drag and drop’ can
be used in the editor.
•
Change object appearance with fill color, stroke color,
width, height, font, font size etc, and add effects like
color gradients or semi-transparency
•
Bind to any signal in a Vista system, to any property
of a graphical object, or bind several Vista signals to
several properties for dynamic behavior.
•
Embed pictures and photos.
•
Automatically convert OGC graphics.
•
Animations and conversions.
•
Javascript for more advanced user interaction.
TAC Vista 5
Graphics Editor TGML
DESCRIPTION
0-008-8222-0 New License
0-008-8322-0 Upgrade
0-008-8422-0 1 Year Maintenance Agreement
A high performance stand-alone software module for
creating and editing dynamic system images.
A broad range of drawing tools, symbols and functions
allows customized and efficient color graphic creation.
•
Extensive standard symbol library
•
Symbol editor
•
Run time simulation
•
Unrestricted tool positioning
•
Multiple graphics
•
Import of .bmp .gif .jpg .pcx .tif graphics files
•
Dynamic and animated graphics as well as creation of
dynamic links
TAC Vista 5 Graphics
Editor OGC
DESCRIPTION
0-008-8221-0 New License
0-008-8321-0 Upgrade
0-008-8421-0 1 Year Maintenance Agreement
Maintenance Agreements - see page 10 for further details.
