References (continued) Software
Supervisory control and data acquisition
software (SCADA)
Vijeo Citect
Vijeo Citect Lite, stand-alone (continued)
Vijeo Citect Lite Point Expansion
The references below are used for increasing the number of Vijeo Citect Lite points
available or to upgrade Lite Server to Full Server.
The licence point count expansion is achieved in steps. For example, if a licence is
upgraded from 100 points to 600 points, 3 part numbers will be ordered to upgrade
from 100 points to 150 points, 150 points to 300 points and 300 points to 600 points.
Designation Number of points Reference Weight
kg
Vijeo Citect Lite
Point Expansion
(number of points)
100 to 150 VJC NS L56-L11 –
150 to 300 VJC NS L11-L27 –
300 to 600 VJC NS L27-L59 –
500 or 600 to 1200 VJC NS L59-L50 –
Vijeo Citect Lite
Point Expansion
(Lite server to Full server)
Lite 150 to Full 150 VJC NS L11-F11 –
Lite 300 to Full 500 VJC NS L27-F12 –
Lite 600 to Full 1500 VJC NS L59-F13 –
Lite 1200 to Full 1500 VJC NS L50-F13 –
Vijeo Citect Server
The Vijeo Citect Server full system licences are segmented according to the number
of points.
Redundant system
b For a redundant system simply order 2 Vijeo Citect Server licences
b No other option is required for the Servers
b The programmed USB key must be ordered separately
Vijeo Citect Server licence
Designation Number of points Reference Weight
kg
Vijeo Citect Server
Full version
Key to be ordered separately
75 VJC NS 1011 10 –
150 VJC NS 1011 11 –
500 VJC NS 1011 12 –
1500 VJC NS 1011 13 –
5000 VJC NS 1011 14 –
15000 VJC NS 1011 15 –
Unlimited VJC NS 1011 99 –
Vijeo Citect Server Point Expansion
The references below are used for increasing the number of points on the Server.
The licence point count expansion is achieved in steps. For example, if a licence is
upgraded from 75 points to 1500 points, 3 part numbers will be ordered to upgrade
from 75 points to 150 points, 150 points to 500 points and 500 points to 1500 points.
Designation Number of points Reference Weight
kg
Vijeo Citect Server
Point Expansion
75 to 150 VJC NS 1011 10-11 –
150 to 500 VJC NS 1011 11-12 –
500 to 1500 VJC NS 1011 12-13 –
1500 to 5000 VJC NS 1011 13-14 –
5000 to 15000 VJC NS 1011 14-15 –
15000 to unlimited VJC NS 1011 15-99 –
Vijeo Citect
Presentation:
pages 6/46 ...
Architectures:
pages 6/48 ...
