System
Dimensions
Cable Capacity
based on typical values for Ø6.5mm, Ø7.0mm and Ø8.4mm data cables*
STERLING
PROFILE
4-13
PVC-U
Comp 1 Comp 2 Comp 3
Comp 4
NO
BOX
WITH
BOX
NO
BOX
WITH
BOX
NO
BOX
WITH
BOX
Profile 4 & 5:
218 x 50mm
Profile 4
Ø6.5mm
Ø7.0mm
Ø8.4mm
18
15
10
–
–
–
54
45
31
19
16
11
52
43
30
17
14
10
–
–
–
Profile 5
Ø6.5mm
Ø7.0mm
Ø8.4mm
22
18
13
–
–
–
54
45
31
19
16
11
52
43
30
17
14
10
–
–
–
Profile 6:
269 x 50mm
Profile 6
Ø6.5mm
Ø7.0mm
Ø8.4mm
52
43
30
17
14
10
54
45
31
19
16
11
52
43
30
17
14
10
–
–
–
Profile 11,
12 & 13:
255 x 50mm
Profile 11
Ø6.5mm
Ø7.0mm
Ø8.4mm
18
15
10
–
–
–
54
45
31
19
16
11
50
42
29
15
13
9
18
15
10
Profile 12
Ø6.5mm
Ø7.0mm
Ø8.4mm
18
15
10
–
–
–
54
45
31
19
16
11
50
42
29
15
13
9
20
17
12
Profile 13
Ø6.5mm
Ø7.0mm
Ø8.4mm
20
17
12
–
–
–
54
45
31
19
16
11
50
42
29
15
13
9
20
17
12
ELEGANCE
170
ALUMINIUM
Comp 1
Comp 2
Comp 3
NO BOX WITH BOX
170 x 55mm
Elegance
170
Ø6.5mm
Ø7.0mm
Ø8.4mm
25
21
14
63
53
37
24
20
14
25
21
14
32 |
3+ compartment trunking
Cable management for data capacity
*All calculations allow for a 45% space factor
(Sterling Profile 4)
50
16
1
2
3
50
21
1
2
3
