TECHNICAL INFORMATION
Technical information
242 |
Material data
Contents
Material data
242
Data compliant trunking
246
GRP Ladder and tray
248
Wire basket
252
Underfloor to desk solutions
258
• MT32 underfloor system
258
• Powertrack, boxes and grommets
259
• Power and data modules
263
PowerPoles and PowerPosts
264
• PowerPoles
264
• PowerPosts
267
PVC-U perimeter trunking systems
269
• Compact
270
• Mono and Mono Plus
272
• Odyssey
274
• Series R
276
• Sterling Profile 1,2 and 3
278
• Sterling Curve
278
• Sterling Profile 4 to 13
278
• Twin165
282
• Twin Plus
284
• XL trunking
286
Aluminium trunking systems
288
• Bench trunking
289
• Elegance
290
• Sterling Profile
291
• Twin Plus
294
• XL trunking
296
Steel trunking systems
298
PVC-U domestic and general trunking
300
• Bench trunking
300
• Cornice trunking
301
• Maxi trunking
302
• Sceptre trunking
302
• Mini trunking
305
• Sovereign Plus trunking
306
Conduit systems
308
• PVC-U conduit
308
• MT Supertube
309
Accessory boxes and enclosures
310
Power, voice and data accessories
311
Fire and security containment systems 312
• Firefly
312
Laboratory and healthcare
313
• Bio antimicrobial trunking
313
• XL aluminium
314
PVC–U material data
Marshall-Tufflex cable management
products are manufactured in Extra
Super High Impact PVC-U grade
material, capable of withstanding the
most hazardous conditions on site
and which exceeds the most stringent
requirements of the British Standards.
Characteristics
Chemical resistance
The material is virtually unaffected by
solutions of inorganic acids, alkalis and
salts and is resistant to many organic
chemicals. It may be softened by some
organic materials such as ketones
and aromatic compounds. It will not
corrode. See Chemical Resistance table
on page 243 for further details.
Fire resistance
The material used in Marshall-Tufflex
conduit and trunking are self-
extinguishing and comply with the
requirements of BS 476 Parts 6 and 7
and BS 4678. Non-flame propagating
to BS EN 50085 and BS EN 61386-1.
(See Characteristics table above)
Thermal properties
Marshall-Tufflex conduit and trunking is
designed to accommodate variations
of ambient temperature equating to
5.25mm/3m for a temperature
rise of 25°C.
Operating temperatures: -5°C to +60°C.
Thermal conductivity: 0.19 w/m/°C.
Impact resistance
High impact resistance. The material
is formulated to comply with the -5°C
clause of BS 4678 Part 4 (1982) Cable
Trunking Standard and the -5°C Heavy
Gauge Requirements of BS EN 61386-1.
Standards
Trunking systems are manufactured
to comply with the requirements of
BS 4678-4:1982 and BS EN 50085-1:
2005+A1:2013 where applicable.
Conduit systems comply with the
requirements of BS 4607-5:
1982+A3:2010 and BS EN 61386-1:2008.
Specific gravity
1.42
Co Efficient of
Linear Expansion
7 x 10 - ⁵/m/˚C
Water Absorption
Negligible
Electric Strength
To the requirements of
BS 4678, BS EN 50085
Fire Performance
BS 476 PT6 & PT7
BS 4678
BS EN 50085
UL94
BS EN 61386-1
BS 4607
PASS
PASS
PASS
V-0 @1.6mm
PASS
PASS
Oxygen Index
42%
Tensile Strength
492/562 kg/cm²
Insulation Resistance
To the requirements of
BS 4678, BS 4607,
BS EN 50085,
BS EN 61386-1
Chemical Resistance
See below
Vicat Softening Point
(conduit & trunking)
80°c
BS EN ISO 306
Vicat Softening Point
(moulded fittings)
76°c
BS EN ISO 306
