PVC-U domestic and general trunking
PVC-U DOMESTIC AND GENERAL TRUNKING
Clear maxi trunking (MTRS50, MTRS100,
MTRS100/50 and fabricated fittings only)
Is available and particularly useful for
high security installations. For further
information please contact our
technical team on +44 (0)1424 856688.
This range is subject to a set up charge.
204 |
Maxi trunking
A mid-size feeder and distribution trunking that can be
subdivided to carry power and data. Larger sizes can
also accommodate wiring accessories.
Product information
•
A variety of sizes from 50 x 50mm to 150 x 150mm
•
Single or divided compartment options
Data information
•
Fabricated data slow bends
MTRS50
code
size
pack
MTRS50WH
50x50mm 8x3m
MTRS75/50
code
size
pack
MTRS75/50WH
75x50mm 4x3m
Trunking profiles
Fittings
Mini trunking adaptor
code
size
pack
TTA2WH
MMT2
10
TTA4WH
MMT4
10
Note:
only for 50mm
trunking depth
MTRS75
code
size
pack
MTRS75WH
75 x 75mm 4 x 3m
MTRS100/50
code
size
pack
MTRS100/50WH
100 x 50mm 4 x3m
MTRS100
code
size
pack
MTRS100WH
100 x 100mm 4 x 3m
MTRS150
code
size
pack
MTRS150WH
150 x 150mm 2 x 3m
Single cover
Single compartments
are subdividable
Colour options:
optional colours
and finishes are available but
these are subject to minimum
quantity orders and longer lead
times. For more information
contact the Technical Team
on +44 (0)1424 856688.
Standard colour
WH
WH
: White
Flanged coupler
code
size
pack
TTRS1WH
MTRS100 TO MTRS100/50 1
TTRS2WH
MTRS100 TO MTRS75
1
TTRS3WH
MTRS100 TO MTRS75/50
1
TTRS4WH
MTRS100 TO MTRS50
1
TTRS5WH
MTRS100/50 TO MTRS75/50 1
TTRS6WH
MTRS100/50 TO MTRS50
1
TTRS7WH
MTRS75 TO MTRS75/50
1
TTRS8WH
MTRS75 TO MTRS50
1
TTRS9WH
MTRS75/50 TO MTRS50
1
TTRS10WH
MTRS150 TO MTRS100
1
TTRS11WH
MTRS150 TO MTRS75
1
See page 239 for
Firefly fire clips
for Mini trunking
NEW
See
page 206
for quick
reference
chart
