PVC-U DOMESTIC AND GENERAL TRUNKING
PVC-U domestic and general trunking General information | 195
0
280
270
260
250
240
230
220
200
190
180
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
210
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180
10 x 8mm to 75 x16mm
Range of small size containment for general wiring. Standard and self-fix
options are available with 1 or 2 compartments.
50 x 50mm
A cornice containment system for distributing services around ceiling perimeters.
This system can be used with Mini Trunking to supply switch drops and
pendant lighting.
Page
196
50 x 50mm to 150 x 150mm
A mid-size containment that can be subdivided for general wiring.
Larger sizes can accommodate wiring accessories.
Page
204
105 x 105mm
Robust angular containment for distributing services
on the desktop or workbench. Can accept standard wiring accessories.
Page
209
Page
211
100 x 25mm and 100 x 40mm
Smallest trunking system that can still accept a full range of standard wiring
accessories. Suitable for unobtrusive, multiple outlet, surface installations.
Page
202
75 x 20mm
Skirting trunking with one piece cover.
Page
212
Note: you may use the rule on the left of this page to check profile sizes.
Environmental
• No increase in dioxin
emission from Municipal
Waste Incineration.
• No phthalates used in
manufacture of PVC-U or
FR-ABS.
• Lead-free formulations are
used for mouldings and
extrusions.
• No use of cadmium-based
stabilisers or pigments.
• Lowest oil content of a
commodity plastic.
Recycling
and sustainability
• PVC-U is a cost-effective,
sustainable choice and
comparable with other
materials such as steel,
aluminium, copper and
wood.
• 100% recyclable material.
• Long life cycle.
• No painting or powder
coating required.
EMI protection
(Electromagnetic interference)
• Some PVC-U systems are
available with a coating
that provides effective
screening against
electromagnetic
interference with no
reduction in cable
capacity.
Fire performance
• The fire rating for PVC-U is
excellent* and PVC-U has all
the characteristics required
for Fire Escape Time.
• Highly resistant to ignition.
• Does little to contribute to the
spread of fire and is classified
to Building Regs: Class 0.
• Has a low rate of smoke
production during the early
stages of a fire.
• Acts as an effective barrier
to flame spread from
malfunctioning electrical
components within systems.
• Chars and is self-extinguishing.
• Does not produce flaming
droplets or burning debris.
• ABS fittings fire rated to UL94V0.
*see the independent report at
