Invicta 3 125A / 250A Type B TP&N distribution board
Characteristics
JK1**
JK2**
Standards
Designed, manufactured and tested to
BS EN 60439-3
Designed, manufactured and tested to
BS EN 60439-3
Busbar Current Rating
125A
250A
Busbar Type
Fully Shrouded Copper
Fully Shrouded Copper
Busbar Rating
25kA Conditional
25kA Conditional
Incoming
100A Switch
250A MCS
125A Switch
250A MCCB
63A Contactor AC3
160A Contactor AC3
100A Contactor AC3
Direct Connection
Direct Connection
More incomer options available
Outgoing Ways
4, 6, 8, 12, 16 Triple pole outgoing ways
8, 12, 16, 18, 24 Triple pole outgoing ways
Outgoing Protection
Type B MCB (0.5A to 63A, 1P and 3P)
Type C, D MCB, (0.5A to 63A, 1P & 3P)
1Mod and 2Mod RCBO (6A to 50A Type B & C,
30mA & 10mA)
Type B MCB (0.5A to 63A, 1P & 3P)
Type C, D MCB, (0.5A to 63A, 1P & 3P)
1Mod and 2Mod RCBO (6A to 50A Type B & C,
30mA & 10mA)
Voltage Rating in AC
230 / 400V
230 / 400V
IP Protection
IP3X to BS EN 60529
IP3X to BS 60529
Enclosure Body Type and Paint Type
Steel, Powder Coat Grey White RAL 9002
Steel, Powder Coat Grey White RAL 9002
Cable Entry
Obround protected cable entry points
Obround protected cable entry points
