klik.lighting distribution system
Occupancy Sensors
• Presence detection mode:
Allows lighting to be controlled
ensuring that lighting is only
energised when people are in
the detection area.
• Absence detection mode:
Requires lighting to be
activated by a wall switch or
remote control to switch
lighting on. Lighting then
remains on during presence
and switches off after time out
period from last presence
detection. Offers potentially
the best energy savings.
• Wall switch override allows
lighting state to be changed
between states.
• High sensitivity detection will
react to small movements,
such as somebody working at
a desk up to 5m diameter.
• Motion detection will react
to larger movements, such as
walking up to 7m diameter.
• Integral photocell 5 - 1000 lux.
Lux setting can be increased
and decreased in increments
of 100 lux.
• EEK001 programming tool is
easy to use with 2 memory
settings to enable
repeatability.
• EEK002 remote control comes
with a wall mounting bracket
for storage and allows room
occupant to have control of
lighting output.
• Time out adjustment:
2 - 57 mins with remote
programmer.
1 min - 1 hour with
potentiometer.
• Switching capability - relay
Incandescent Halogen -
2300W.
Halogen ELV via ferromagnetic
or electronic transformer -
1500W.
Compact Fluorescent -
23 x 23W.
Parallel compensated
fluorescent tubes - 1000W
Fluorescent via electronic
ballast - 1000W.
• Walk test mode.
• Factory presets:
Lux = 400
Time = 20 min
Test mode for 2 min.
• 3m 1.5mm
2
Low Smoke Zero
Halogen.
• Can be flush mounted through
a 60mm hole, utilises spring
clips to ensure a fast and
secure mounting method.
• All parts factory connected
and tested.
• Time and photocell can be set
by controller EEK001 or
potentiometer.
For technical information see pages 39-41. For product standards see page 34.Occupancy Sensors
Description
Pack qty.
Cat ref.
Standard Occupancy Sensor, Pre-Wired 3m
1
EEK513W
Standard Occupancy Sensor, Pre-Wired 5m
1
EEK515W
Standard Occupancy Sensor (without cable)
1
EEK510B
Surface Mount Kit
1
EEK005
Programming Tool & Remote Controller
Description
Pack qty.
Cat ref.
Programming Tool
1
EEK001
Remote Control
1
EEK002
EEK510B
EEK001
EEK002
