General Catalogue • Technical • tebis.KNX
Radio:
Push Buttons and Remote Controls
TD1**
TD2**
TD25***
TD3***
TD Push Button (KNX Radio)
These are unidirectional or standard EIB / KNX emitters. The radio
extra flat push buttons are offered in 2 colours (white and silver) and
in 2, 4 or 6 ways version (keys with left / right horizontal direction). All
products are with the label folder, and with a radio emission LED. The
allocation of the ways is carried out with the TX100GB configurator.
Technical Characteristics
KNX Radio Push Button
Supply
CR2430 (3V) battery cell
Life of the battery
3 years
Emission range
• Inside a building
Max. 30m
• Open area
Max. 100m
Emission frequency
868.3MHz
Working temperature
0ºC to +45ºC
Storage temperature
-20ºC to +70ºC
Protection index
IP30
Size
80.5 x 80.5 x 12mm
How to Choose RF Push-Buttons
Number of Commands 1 Key
2 Ways
2 Keys
4 Ways
3 Keys
6 Ways
2 Keys 4 Ways + Solar
Colour
White
Silver
White
Silver
White
Silver
White
Silver
With label holder
TD110
TD111
TD210
TD211
TD310
TD311
TD250
TD251
Without label holder
TD100
TD101
TD200
TD201
TD300
TD301
-
-
Supply
2 Cr 2430 (3V) battery - 3 years
Radio Remote Controls
These are unidirectional emitters in standard EIB/KNX.
The allocation of the keys is carried out with TX100GB configuration.
Technical Characteristics
TU402/404/406/418
Supply
CR2430
Life of the battery
3 years
Emission range
• Inside a building
Max. 30m
• Open area
Max. 100m
Emission frequency
868.3 Mhz
Working temperature
0ºC to +45ºC
Storage temperature
-20ºC to +70ºC
Protection index
IP30
Size
111 x 51 x 18mm
