4.32 General Catalogue • Protection Devices • Technical
Type 1 & 2 Surge Protection Devices
SPA215*, SPA400*, SPA401*
SPA201 SPA400 SPA401
Tested to EN 61643-11 2002-12
SPD type / class Type 1 + Type 2 / Class I
Energy-coordinated
protection effect on terminal
equipment
Type 1 + Type 2
Energy-coordinated
protection effect on
terminalequipment ≤ 5 m
Type 1 + Type 2 + Type 3
Type of connexion Parallel connection
Type of power supply
system
TT / TN system TN-C-S TT / TN-S system
Type of protection common and differential modes common modes common and differential modes
Nominal voltage UN 230V/400V ac
Rated voltage Uc 255V ac
Voltage protection level Up ≤ 1.5kV
TOV Voltage UT 440V / 5s 1200V / 200ms 440V / 5s 440V / 5s 1200V / 200ms
Rated load current I(L) n/a
I(L-L) n/a
Follow current interrupting
rating
Ifi 25kA rms 100A rms 25 kA rms 25kA rms 100A rms
Nominal discharge current
(8/20)
In 12.5kA 25kA 12.5kA (L-PEN) 37.5kA (total) 12.5kA 50kA
Impulse current (10/350) Iimp 12.5kA 25kA 12.5kA (L-PEN) 37.5kA (total) 12.5kA 50kA
Max. rating of overcurrent
protection
fuse 160A gL / gG
MCCB n/a 160A
Short-circuit withstand
capability with max.
overcurrent protection
fuse 25kA rms
MCB n/a
Response time tA ≤ 100ns
Operating temperature
range
- 40°C ….+ 80°C
Indication of SPD
disconnector
Green/Red flag on L and N Green/Red flag on L1, L2, L3 Green/Red flag on L1, L2, L3
and N
Cross sectional area min 1,5mm2 solid / flexible
max 35mm2 stranded / 25mm2 flexible
Tightening torque for
terminals
4 Nm
Mounting on 35mm DIN rail in accordance with EN 60715
Enclosure material grey thermoplastic, UL 94V-0
Degree of protection IP20
Modular width 2 4 4
Weight 275 g 386 g 480 g
Approval marking KEMA
