TRUNKING HINGED LIDS
A patented two stage location gives a hinge
effect, enabling cables to be supported by the
trunking cover during the installation. Cover
design avoids dust traps and makes cleaning
easier and continues the aesthetics of the
trunking.
STYLING LINES
All fittings are moulded with
styling lines for aesthetic
continuity.
ELECTROMAGNETIC INTERFERENCE
Additional data cable/signal protection is provided
by fitting screening divider VCT30.
FLAT TEES AND ANGLES
The ingenuity of the patented tee design allows a variety of cable drop permutations. The tee’s bridge can
be fitted in two positions increasing the versatility of cable runs whilst maintaining the correct segregation
and Cat 5e, 6 and 7 compliance. Screw fixing hole locations have a protective shroud to prevent the chafing
of cables.
Both the Flat Angle and Tee compartment divider walls are curved (Cat 5e, 6 and 7 compliant) to allow data
cables to lay in with no loss of capacity. The covers are one piece and clip securely into place, and the base
is also a single moulded item, giving more strength than fabrication. Joint covers are not required where the
tee/angle meets the trunking as the moulded covers now overlap the junction.
EXTERNAL CORNER
External Corners accommodate +/- 5
degree irregularities in the squareness of
a corner. Corners come ready assembled
to click into place, and offset side
splits hide the effect of the split line for
aesthetics.
DATA SWEEP
The unique patented Data Sweep
provides Cat 5e, 6 and 7 data cabling
compliance, with no loss of capacity and
without the need for bulky, protruding
corner covers.
CHOICE OF TWO PROFILES
Available in Dado and
Skirting profiles to suit most
installations.
Available in white and charcoal.
