INTERNAL CORNER
Designed to accommodate irregularities in the
squareness of the corner with a +/- 5 degree
flexibility range. The centre split gives maximum
adjustment. Covers are radiused and compatible
with Cat 5e, 6 and 7 data cabling requirements.
PRE-PUNCHED BASES
Wall fixing is simplified by the inclusion
of pre-punched oval holes at 100mm
intervals, ensures no drilling is required.
MOUNTING FRAMES
1 gang and 2 gang ‘open box’ mounting frames use
the full trunking depth allowing ease of connection to
power and data devices. The open top/bottom allows
unhindered tool free cable entry through the trunking
compartment divider knockout. The frame can slide to
align with appropriate knockout.
END CAPS
Neatly finishes runs of trunking.
Moulding provides internal
location for extra security from
optional screw fixing.
SCREW FIXING KIT
Where higher security is required, all fitting covers
can be secured using the Screw Fixing Kit. The Screw
Fixing Kit is self-locating on the styling line of the
system and has a cover to hide the screw head.
DIVIDER KNOCKOUTS
Wiring is also made easy with
50mm x 21mm knockouts
at 100mm intervals along
compartment dividers, providing
instant access to mounting boxes
with no drilling or cutting.
