INTERNAL CORNER
Designed to accommodate irregularities in the
squareness of the corner with a +/- 5 degrees
flexibility range. The centre split gives maximum
adjustment. Covers are radiused and compatible
with Cat 5e, 6 and 7 data cabling requirements.
PRE-PUNCHED BASES
Wall fixing is simplified by the inclusion
of pre-punched oval holes at 100mm
intervals, ensures no drilling is required.
BACK BOXES
1, 2 and 3 gang 45mm deep back boxes and 1 and 2 gang
40mm frames ensure Cat 5e, 6 and 7 compliance and ease
of connection to power and data devices. The open top/
bottom allows unhindered tool free cable entry, through the
trunking compartment divider knockout. The back box can
slide to align with appropriate knockout (see technical pages
for restrictions on use).
END CAPS
Neatly finishes runs of trunking.
(Moulding provides internal
location for extra security from
optional screw fixing).
SCREW FIXING KIT
Where higher security is required,
e.g. schools, all fitting covers can be
secured using the Screw Fixing Kit.
The Screw Fixing Kit is self-locating
on the styling line of the system and
has a cover to hide the screw head.
DIVIDER KNOCKOUTS
Wiring is also made easy with
50 x 21mm knockouts at 100mm
intervals along compartment
dividers, providing instant access
to mounting boxes, with no drilling
or cutting.
PART M
Compliance to Part M
building regulations
can be achieved
using Part M flange or
charcoal devices.
