MK Electric Catalogue No. 49

234 / 759

Blank Plates
K3390ALM 5
K3390WHI 5
1 GANG
K3369ALM 5
K3369WHI 5
2 GANG
DIMENSIONS
K3390 86 x 86mm
K3369 86 x 147mm
FIXING CENTRES
K3390 60.3mm
K3369 120.6mm
BS 5733:2010
Blank plates supplied without
backboxes.
Grid Plus
Frontplates
K3491ALM 10
1 MODULE
K3492ALM 10
2 MODULE
K3493ALM 5
3 MODULE
K3494ALM 5
4 MODULE
K3496ALM 1
6 MODULE
K3498ALM 1
8 MODULE
K3499ALM 1
9 MODULE
K3502ALM 1
12 MODULE
K3508ALM 1
18 MODULE
K3514ALM 1
24 MODULE
DIMENSIONS
1 & 2 module 86 x 86mm
3 & 4 module 86 x 146mm
6 & 8 module 146 x 146mm
9 & 12 module 146 x 206mm
18 module 206 x 206mm
24 module 206 x 266mm
BS 5733:2010
See Grid Plus page 189 for a complete
selection of switching modules.
K3494ALM
K3502ALM
K3492ALM
K3491WHI 10
1 MODULE
K3492WHI 10
2 MODULE
K3493WHI 5
3 MODULE
K3494WHI 5
4 MODULE
K3494WHI
K3491WHI
K3369ALM
K3369WHI
K3390ALM
K3390WHI K3492WHI
K3493WHI
Boxes
K829ALM 5
1 GANG
WITHOUT KNOCKOUTS
K830ALM 5
2 GANG
WITHOUT KNOCKOUTS
K899ALM 10
K899WHI 10
1 GANG
6 X 20MM KNOCKOUTS
All boxes are fitted with a brass earth
terminal and a base knockout.
DIMENSIONS
1 gang 86 x 86 x 38mm
2 gang 86 x 147 x 38mm
These boxes are not suitable for
mounting Grid Plus modules or
modular data/telecom modules.
BS 5733:2010
K829ALM
K830ALM
K899ALM
K897WHI
K897ALM 5
K897WHI 5
2 GANG
8 X 20MM KNOCKOUTS
K899WHI
K897ALM
