perimeter and distribution
|
cable management
5
Prestige
3
D
Dado and Skirting
*Minimum order value. Contact Design Service for details.
EXTERNAL CORNER
External Corners accommodate +/- 5 degree
irregularities in the squareness of a corner. Corners
come ready assembled to click into place, and offset
side splits hide the effect of the split line for aesthetics.
FLAT TEES AND ANGLES
The ingenuity of the patented tee design allows a variety of cable drop permutations. The
tee’s bridge can be "tted in two positions increasing the versatility of cable runs whilst
maintaining the correct segregation and Cat 5e, 6 and 7 compliance. Screw "xing hole
locations have a protective shroud to prevent the cha"ng of cables. Both the Flat Angle
and Tee compartment divider walls are curved (Cat 5e, 6 and 7 compliant) to allow data
cables to lay in with no loss of capacity. The covers are one piece and clip securely into
place, and the base is also a single moulded item, giving more strength than fabrication.
Joint covers are not required where the tee/angle meets the trunking as the moulded
covers now overlap the junction.
TRUNKING HINGE LIDS
A two stage location gives a hinge effect,
enabling cables to be supported by the
trunking cover during the installation.
Cover design avoids dust traps and
makes cleaning easier, and continues the
aesthetics of the trunking.
DATA SWEEP
The unique patented Data Sweep provides Cat 5e, 6 and
7 data cabling compliance, with no loss of capacity
and without the need for bulky, protruding corner
covers.
ELECTROMAGNETIC INTERFERENCE
Additional data cable/signal protection is
provided by "tting screening divider VP30.
CHOICE OF TWO
PROFILES
Available in Dado and
Skirting pro"les to suit
most installations.
Available in white,
charcoal and choice of
RAL colours*.
STYLING LINES
All "ttings are moulded
with styling lines for
aesthetic continuity.
