Prestige
3
D
Dado and Skirting
INTERNAL CORNER
Designed to accommodate irregularities
in the squareness of the corner with a
+/- 5 degrees !exibility range. The centre
split gives maximum adjustment. Covers
are radiused and compatible with Cat 5e,
6 and 7 data cabling requirements.
PRE-PUNCHED BASES
Wall "xing is simpli"ed by the
inclusion of pre-punched oval
holes at 100mm intervals, ensures
no drilling is required.
BACK BOXES
The 1 and 2 gang 35mm and 45mm deep back boxes, 3 gang
45mm deep back box and 1 and 2 gang 40mm frames ensure
Cat 5e, 6 and 7 compliance and ease of connection to power
and data devices. The open top/bottom allows unhindered tool
free cable entry, through the trunking compartment divider
knockout. The back box can slide to align with appropriate
knockout (see technical pages for restrictions on use).
END CAPS
Neatly "nishes runs
of trunking. (Moulding
provides internal location
for extra security from
optional screw "xing).
SCREW FIXING KIT
Where higher security is required,
e.g. schools, all "tting covers can be
secured using the Screw Fixing Kit.
The Screw Fixing Kit is self-locating
on the styling line of the system and
has a cover to hide the screw head.
DIVIDER KNOCKOUTS
Wiring is also made easy
with 50 x 21mm knockouts
at 100mm intervals along
compartment dividers,
providing instant access to
mounting boxes, with no
drilling or cutting.
PART M
Compliance to Part M
building regulations
can be achieved
using Part M !ange,
charcoal devices
or charcoal straight
cover.
