TE5 light indicators
7/13
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
7
■
Technical specifications
Color coding according to IEC 60073
■
Selection and ordering data
5
TE5 8
Standards
DIN VDE 0710-1
Rated operational voltage U
e
Max.
V AC 230 (for different voltages see 5TG8 lamps)
Rated power dissipation P
v
VA See 5TG8 lamps
Clearances
Between the terminals
mm > 7
Terminals
± screw (Pozidriv)
1
Max. tightening torque
Nm 1.2
Conductor cross-sections
Rigid
mm
2
1.5 ... 6
Flexible, with end sleeve
mm
2
1 ... 6
Permissible ambient temperature
°C -5 ... +40
Resistance to climate
At 95 % relative humidity
Acc. to DIN 50015
°C 45
5
TG8 05.
Rated power dissipation P
v
•
LED
VA 0.4
•
Glow lamp
VA 0.4
Meaning
Color
Safety of people
and environment
Process state
System state
Red
Danger
Emergency
Faulty
Yellow
Warning/Caution Abnormal
Green
Safety
Normal
Blue
Stipulation
White
Gray
No special significance assigned
Black
Version
U
e
Conductor
cross-
sections
MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
V AC Up to mm
2
Unit(s) Unit(s) kg
Light indicators for max. cable length up to 5 m
With 1 red lamp
230 6
1
}
5
TE5 800
027 1
1/12 0.060
With 2 lamps, red and green
}
5
TE5 801
027 1
1
0.056
With 3 green lamps
}
5
TE5 802
027 1
1
0.063
With 3 lamps, red,
yellow and green
}
5
TE5 803
027 1
1
0.063
Light indicators for max. cable length up to 250 m
With 1 red lamp
230 6
1
B
5
TE5 804
027 1
1
0.060
