BETA Protecting
SR60 Busbar Systems
Mounting components
5/20
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
5
■
Selection and ordering data
Length DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
mm
Unit(s) Unit(s) kg
Bases
Height
230
mm, for 3 busbars
1100
B
5
SH3 526
016 1
1
1.100
290
mm, for 4 busbars
C
5
SH3 527
016 1
2
1.300
Blanking covers
Mounting on 5SH3 536 supports for
blanking covers, height 202 mm
1000
A
5
SH3 537
016 1
2
0.075
Edges
17
x 36 mm, for 3 busbars
1100
B
5
SH3 528
016 1
2
0.311
77
x 36 mm, for 4 busbars
C
5
SH3 530
016 1
2
0.583
Partitions
For additional touch protection on systems
without bases, slotted
17
× 86 mm
1100
C
5
SH3 531
016 1
2
0.365
8
US19 22-1AC00
5
SH3 534
End covers
For covering free busbar ends
L1–L3, for 8US19 23-2AA01 or
8
US19 23-3AA01
A
8
US19 22-1AC00
143 1
10 0.020
L1–L3+PE/N, 4P,
for 8US19 23-4AA00
(1
pack = 2 units, (1x right, 1x left))
A
8
US19 22-1AB00
143 1
1
0.055
For 5SH3 532 holders
Height 230 mm (3P)
B
5
SH3 533
016 1
4
0.038
Height 290 mm (4P or 3P + wiring duct),
(1
pack = 2 units, (1x right, 1x left))
C
5
SH3 534
016 1
4/40 0.048
Holders
For edges and partitions
5
SH3 528, 5SH3 530 and 5SH3 531
B
5
SH3 532
016 1
2
0.106
Supports for blanking covers
For blanking covers,
mounting on busbar
(2
units required for each section of
blanking cover)
B
5
SH3 536
016 1
4/160 0.040
Busbar supports
For SR60 busbar system
For busbars with a bar thickness of
5
or 10 mm and a busbar height
of 12, 15, 20, 25 or 30 mm
L1–L3, 3P, with outer mounting
A
8
US19 23-2AA01
143 1
10 0.200
L1–L3, 3P, with inner mounting
A
8
US19 23-3AA01
143 1
10 0.200
L1–L3+PE/N, 4P, with inner mounting
A
8
US19 23-4AA00
143 1
10 0.269
