BETA Protecting
SR60 Busbar Systems
Built-in components
5/15 Siemens ET B1 · 10/2008
5
■ Dimensional drawings
NEOZED SR60 bus-mounting bases
DIAZED SR60 bus-mounting bases
D02/63 A
(a = 27 mm, t = bar thickness)
D02/63 A
(a = 27 mm, b = 50 mm)
D02/63 A
(a = 36 mm, b = 50 mm)
5SG6 202 (t = 5 mm) 5SG6 206 5SG6 207
DII/25 A
(a = 42 mm)
DIII/63 A
(a = 57 mm)
DII/25 A
(a = 42 mm)
DIII/63 A
(a = 57 mm)
5SF6 014, 5SF6 015
(t = 5 mm)
5SF6 214, 5SF6 215
(t = 5 mm)
5SF6 018, 5SF6 020
(b = 70 mm)
5SF6 218, 5SF6 220
(b = 70 mm)
60
60
177
a
I2_07478a
23
t
33,5
55
169 189194200
60
60
I2_13998
a 32
35
43
b 28
60
60
a
I2_07497
36
43,5
t
169
66
60
60
169
a
I2_07496
36
43,5
t
66
169 189194200
60
60
I2_13998
a 32
35
43
b 28
