BETA Protecting

Miniature Circuit Breakers

Configuration

1/81

Siemens ET B1 · 10/2008

1

*

You can order this quantity or a multiple thereof.

Personnel safety with miniature circuit breakers

According to DIN VDE 0100-410, in order to protect against

dangerous leakage currents in the TN system, the cross-sections

of the conductor, or its distance from the protective device, must

be dimensioned such that if a fault with negligible impedance

(

i.e. short circuit) occurs at any point between a phase conductor

and a PE conductor, or a connected exposed conductive part,

the device automatically trips within the specified times of 0.4 s

or 5 s.

This requirement is met through the following condition:

Z

s

×

I

a

U

o

Maximum permissible impedance of fault loop at U

o

= 230 V AC for compliance with trip conditions according to DIN VDE 0100-410

Z

s

r

Impedance of the fault loop of all electrical circuits

I

a

r

Current that trips within the specified times

U

o

r

Voltage against ground

I

n

[

A]

Characteristic A Characteristic B Characteristic C Characteristic D

t

a

0.4

s 5 s

t

a

0.4

s 5 s

t

a

0.4

s 5 s

t

a

0.4

s 5 s

5

SY, 5SP

0.3

--

--

--

--

76.6

153

--

--

0.5

--

--

--

--

46

92

--

92

1.0

76.6

76.6

--

--

23

46

15.3

46

1.6

47.9

47.9

--

--

14.4

28.8

9.6

28.8

2

38.3

38.3

--

--

11.5

23

7.6

23

3

25.5

25.5

--

--

7.7

15.4

5.1

15.4

4

19.1

19.1

--

--

5.8

11.6

3.8

11.6

6

12.7

12.7

7.6

7.6

3.8

7.6

2.5

7.6

8

--

--

--

--

2.8

5.7

1.9

5.7

10

7.6

7.6

4.6

4.6

2.3

4.6

1.1

4.6

13

--

--

--

3.57

1.7

3.4

0.9

3.4

16

4.7

4.7

2.9

2.9

1.4

2.8

0.7

2.8

20

3.8

3.8

2.3

2.3

1.1

2.2

0.5

2.2

25

3.0

3.0

1.8

1.8

0.9

1.8

0.4

1.8

32

2.4

2.4

1.4

1.4

0.7

1.4

0.3

1.4

40

1.9

1.9

1.1

1.1

0.6

1.2

0.28

1.2

50

--

--

0.9

0.9

0.5

1.0

0.23

1.0

63

--

--

0.7

0.7

0.4

0.8

0.2

0.8

80

--

--

--

--

0.3

0.6

0.14

0.6

100

--

--

--

--

0.2

0.4

0.1

0.4

125

--

--

--

--

0.16

0.3

0.1

0.3

At U

o

= 240 V AC,

Z

s

× 1.04 applies.

At U

o

= 127 V AC,

Z

s

× 0.55 applies.
