CS sheet steel wall-mounting enclosure

2010

CA08103002Z-EN

www.eaton.com

21/3

Indoor installation

CS sheet steel wall-

mounting enclosure

Internal concealed horizon-

tal door hinge pins with

quick change technology so

that the door can be rapidly

taken off its hinges to per-

form further processing or

to change the door stop

Door profile molding

with perforation at 25 mm

intervals for fastening DIN

mounting rails or for fixing

cable conduits and leads

The supplied galvanized

sheet steel mounting plate

permits safe installation of

the switchgear and basic

EMC protection. Slots

facilitate insertion of the

equipped mounting plate

into the control panel.

In the case of enclosure

dimensions larger than

600

x 400 mm bended sides

increase the stability of the

mounting plates when

heavy built-in devices units

are being used.

Optional internal door for

additional personal and

system protection

￫Page 21/4

Mounting plate,

unperforated, galvanized

or RAL 2000

￫Page 21/8

Mounting plate,

perforated, galvanized,

for cage nuts

For quick mounting of

switchgear and protective

devices without drilling

￫Page 21/7

Mounting rail module for

soft starters

Allows convenient

connection and operation

of Eaton soft starter through

pivoting in and out

￫Page 21/6

Depth adjustment

elements for mounting

plates

Depth adjustment in a

mm grid for tailored

surface-mounting on front

or back of mounting plate

￫Page 21/7

Mounting bars for

door profile moldings

and cable ducts

For screw- and hole-less

mounting of Eaton cable

ducts KL...

￫Page 21/6, ￫ 21/21

Universal brackets for

door contact switches

and cable conduit holders

￫Page 21/6

Quick-C

hinge pin

Door hinge pin with

quick-change technology

for retrofitting or as spare

part

￫Page 21/6

Outdoor installation

CS sheet steel wall-

mounting enclosure

Degree of protection IP66,

resistance of impact IK09,

UL/CSA Type 1 and 12

enclosure sizes from

250

x 200 x 150 mm to

1200

x 1200 x 250 mm

(

h x w x d) also with an

enclosure depth of 300 mm.

Impact-resistant designer

metal locks, standard 3 mm

two-way key bit

Rain gutter profile

Foamed polyurethane

sealing throughout.

￫Page 21/4

Rain canopy

With edge sloping toward

rear.

￫Page 21/13

Lift eye kit with profile

bracket

Stable profile bracket

for internal enclosure

reinforcement for lifting eye

￫Page 21/14

Wall fixing bracket

Elongated holes simplify

mounting the equipped

enclosures on the wall

bolts.

Simple subsequent

alignment of enclosure

Vertical and horizontal

mounting possible

￫Page 21/10

Mast fastening

For stable, reliable fixing on

round or rectangular masts

￫Page 21/14

Bottom panels without

apertures

Sheet steel bottom panels

with foamed gasket for

assembly by user

Suitable for indoor or

outdoor installation.

The enclosure can be

turned through 180° for

cable entry from above or

below.

The flange aperture is in the

rear area of the enclosure,

enabling easy wiring onto

the mounting plate.

￫Page 21/11

Bottom panels with

apertures for F3A flanges

Sheet steel bottom panels

with foamed gasket,

preassembled for Eaton F3A

flanges

￫Page 21/11

F3A flanges

Insulating material flanges

with metric knockouts,

cable grommets or push-

through seals.

￫Page 21/12

Metric cable glands

to EN 50262, metric

ventilation cable glands

Innovative ventilating cable

glands

Protection type IP69K

￫Page 21/17, ￫ 21/18

Metric diaphragm

grommets, cable grommet

Protection type up to IP66

￫Page 21/19

Cable interconnect frame

Cable clamp rails can be

fitted at an adjustable

height and depth

￫Page 21/12

Lock for half-cylinder

comfort rotary handle

Standard locks can be

quickly equipped with

cylinder locks.

New and unique on the

market: With built-in

“

closed” position indica-

tion; rugged metal design

No complicated drilling,

punching or sawing of the

door required

The standard lock does

not even have to be

dismounted.

￫Page 21/10

Cylinder locks

High-grade cylinder locks

with adjustable hammer

￫Page 21/10

Locks with inserts,

lock cylinder

Lock for retrofitting

￫Page 21/10

Locks with inserts,

two-way key bit

Lock for retrofitting with

mm or 5 mm two-way key

bit

Made completely of

pressure-cast zinc, there-

fore suitable for indoor

and outdoor installation

￫Page 21/10

Ventilating louvers

For passive control panel

ventilation

￫Page 21/14

Circuit diagram pockets

insulating material

￫Page 21/17
