Circuit-breakers, switch-disconnectors

Construction size 2: accessories

2010 CA08103002Z-EN

17/205

Construction size 2:accessories

Toggle lever locking device

NZM2/3-XKAV

① Up to 3 padlocks

Side-mounted handle

NZM2...-XSH...

① Up to 3 padlocks

Drilling template

F

88

a

92.5

50

1.3

a

d

b

d = 4 – 8

b

f

34

Part no.

a

NZM2, PN2, N2

52.5

NZM3, PN3, N3

70

F

600

80

184

54

30

25

f

R75

R180

35

19.5

145

174.4

d

b

d = 4 – 8

b

f

34

NZM2...-XKAV, NZM2...-XSH
