Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

271 / 543

2010 CA08103002Z-EN
Circuit-breakers, switch-disconnectors
Active power loss
Fixed mounted
NZM2- NS2- N2-, PN2- NZM3-
A...(-NA) M... AF...-NA S...-CNA ...-NA A.../S...
P B P B P B P B P B P B P B
[W] [μohms] [W] [μohms] [W] [μohms] [W] [μohms] [W] [μohms] [W] [μohms] [W] [μohms]
– – – – – – – – – – – – – –
– – – – – – 5.8 750000 – – – – – –
– – – – – – – – – – – – – –
– – – – – – 7.8 450000 – – – – – –
– – – – – – – – – – – – – –
– – – – – – 0.3 4600 – – – – – –
– – – – – – 0.9 4600 – – – – – –
– – – – – – 0.5 1200 – – – – – –
– – – – 2.9 4250 – – – – – – – –
– – – – – – 1.2 1200 – – – – – –
5.1 4250 5.1 4250 5.1 4250 – – – – – – – –
8 4250 8 4250 5.9 3140 – – – – – – – –
– – – – – – 1.6 780 – – – – – –
– – – – 8.5 3140 – – – – – – – –
9.6 3140 9.6 3140 – – – – – – – – – –
– – – – – – 2.5 780 – – – – – –
– – – – 10.3 2800 – – – – – – – –
13.4 2800 13.4 2800 13.4 2800 1.5 317 – – – – – –
– – – – 13.8 2270 – – – – – – – –
17 2270 17 2270 17 2270 2.4 317 – – – – – –
– – – – 18.4 1700 – – – – – – – –
20.2 1700 20.2 1700 – – 3.8 317 – – – – – –
– – – – 15.7 1070 – – – – – – – –
20.5 1070 20.5 1070 20.5 1070 6.1 317 – – – – – –
– – – – 20.8 855 – – – – – – – –
25.7 855 25.7 855 25.7 855 9.5 317 – – – – – –
– – – – 21.4 589 – – – – – – – –
27.6 589 27.6 589 27.6 589 14.9 317 – – – – – –
– – – – 33.6 500 – – – – – – – –
38.4 500 38.4 500 – – 24.3 317 24.3 317 19.7 256
– – – – 36.8 400 – – – – – –
48 400 48 400 48 400 38 317 38 317 30.7 256
– – – – 47.1 310 – – – – – –
58.1 310 – – 58.1 310 59.4 317 59.4 317 48 256 68 364
83.7 310 – – 83.7 310 85.6 317 – – – – 79 256
72 151
93 124
17/175
NZM1, NZM2, NZM3, NZM4
Notes: The values stated in the table apply for 3 and 4 pole fixed
mounted devices with an equal load distribution.
On 4 pole devices the current in the neutral conductor is equal to zero.
The total resistive load is the measured value for a 3 pole or a 4 pole
switch (independent of In and the type of release).
The total resistive load for a switch or withdrawable plug results from:
the resistive value for fixed mounting + resistive value
for plug-in or withdrawable.
The heat dissipation can be calculated with the
formula: P = 3 x R x I²
