17/50 Circuit-breakers, switch-disconnectors
Switch-disconnectors, ATEX
2010 CA08103002Z-EN
Switch-disconnectors,ATEX
Fixed mounting
Number of
conductors
Rated current =
Rated
uninterrupted
current
Short-circuit
protection,
max. fuse
gL-characteristic
Part no.
Article no.
Price
See price
list
Std. pack
In = Iu
A A gL
Switch-disconnectors for ATEX type
2 switch positions Ι, 0
3 pole 125 125 PN1-125/HIV/DA-SVD-SW/ATEX22
119386
1 off
160 160 PN1-160/HIV/DA-SVD-SW/ATEX22
119387
200 250 PN2-200/HIV/DA-SVD-SW/ATEX22
119388
240 250 PN2-250/HIV/DA-SVD-SW/ATEX22
119389
400 630 PN3-400/HIV/DA-SVD-SW/ATEX22
119410
630 630 PN3-630/HIV/DA-SVD-SW/ATEX22
119411
6 pole 160 160 2PN1-160/HIV/DA-SVD-SW/ATEX22
119418
6 pole 250 250 2PN2-250/HIV/DA-SVD-SW/ATEX22
119419
ATEX switches for EMC type
3 pole 125 125 PN1-125/HIV/DA-SVD-SW/EMV/ATEX22
119412
160 160 PN1-160/HIV/DA-SVD-SW/EMV/ATEX22
119413
200 250 PN2-200/HIV/DA-SVD-SW/EMV/ATEX22
119414
240 250 PN2-250/HIV/DA-SVD-SW/EMV/ATEX22
119415
400 630 PN3-400/HIV/DA-SVD-SW/EMV/ATEX22
119416
630 630 PN3-630/HIV/DA-SVD-SW/EMV/ATEX22
119417
Notes Main switch characteristics including positive operation to IEC/EN 60204, VDE 0113.
Isolating characteristics to IEC/EN 60947-3, VDE 0660.
Protection against electric shock to VDE 0160 part 100.
ATEX = Atmosphères explosibles = explosive atmospheres
Eaton supplies switch-disconnectors PN1, PN2 and PN3 for a current range of up to 630 A as complete device according
to ATEX Directive 94/9 EG (binding as of 06/2003).
The switches are approved for device group II, the application “everything, except for mining” and for category 3
(normal safety).
Switch-disconnectors in surface mounting enclosure with ATEX approval are used in potentially explosive dust-laden
areas, such as mills, metal grinding works, wood processing operations, cement works, the aluminum industry, the
foodstuffs industry, grain storage and processing plants, agriculture, and in the pharmaceuticals industry.
ATEX switches for EMC are suitable for use with screened cables.
For important general flush mounting and application notes, see the included installation instructions AWA1230-2480,
which you can also download from our homepage .
PN...ATEX HPL17050EN
