Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

126 / 543

17/30 Circuit-breakers, switch-disconnectors
Circuit-breakers, thermomagnetic releases, 4 pole
2010 CA08103002Z-EN
Fixed mounting
with screw terminals
Switching
capacity
400/415 V
50/60 Hz
Rated current =
Rated uninterrupted current
Setting range Part no.
Article no.
Price
See price
list Overload releases Short-circuit
releases
Phase
conductors
Neutral
conductor
Phase
conductors
Non-delayed
Icu In = Iu Ir x%of phase
conductor
Ir Ir Ii = In x …
kA A % A A
System and cable protection
Comfort switching capacity
36 125 100 100-125 100…125 6-10 NZMC2-4-A125
271430
S
160 100 125-160 125…160 6-10 NZMC2-4-A160
271432
S
160 60 125-160 80…100 6-10 NZMC2-4-A160/100
271433
S
200 100 160-200 160…200 6-10 NZMC2-4-A200
271435
S
200 60 160-200 100…125 6-10 NZMC2-4-A200/125
271436
S
250 100 200-250 200…250 6-10 NZMC2-4-A250
271438
S
250 60 200-250 125…160 6-10 NZMC2-4-A250/160
271439
S
300 100 240-300 240…300 6-10 NZMC2-4-A300
107584
S
300 60 240-300 160…200 6-10 NZMC2-4-A300/200
107585
S
320 100 250-320 250…320 6-10 NZMC3-4-A320
109688
S
320 60 250-320 160…200 6-10 NZMC3-4-A320/200
109689
S
400 100 320-400 320…400 6-10 NZMC3-4-A400
109690
S
400 60 320-400 200…250 6-10 NZMC3-4-A400/250
109691
S
500 100 400-500 400…500 6-10 NZMC3-4-A500
109692
S
500 60 400-500 250…320 6-10 NZMC3-4-A500/320
109693
S
Normal switching capacity
50 20 100 15-20 15…20 350 A fixed Screw terminals as
accessories
25 100 20-25 20…25 350 A fixed
32 100 25-32 25…32 350 A fixed
40 100 32-40 32…40 8-10
50 100 40-50 40…50 6-10
63 100 50-63 50…63 6-10
80 100 63-80 63…80 6-10
100 100 80-100 80…100 6-10
125 100 100-125 100…125 6-10
160 100 125-160 125…160 1280 A fixed
I
NZM...-4-A HPL17030EN
